| Element Collapse pressure | 10 bar (145 PSI) |
| Filtration Media | Inorganic Microfibers 25 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 25 µm |
| Flow direction | Out-In |
| Body Height | 156 mm (6 5/32") |
| Height-1 | 1.1 mm (1/32") |
| Total Height | 157.1 mm (6 3/16") |
| Thread | UN 2 inch Female Bottom 16 |
| Type | UN |
| Thread Size | 2 inch |
| Orientation | Female |
| Position | Bottom |
| Bypass Valve Opening Pressure | 1.75 bar (25 PSI) |
| Largest Inner Diameter | 64 mm (2 17/32") |
| Smallest Inner Diameter | 26 mm (1 1/32") |
| Largest Outer Diameter | 97 mm (3 13/16") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Baldwin | BT8426MPG |
| Claas | 3174370 |
| Clark Michigan | 4202505 |
| Clark Michigan | 4202525 |
| Dana Spicer | 4206169 |
| Dana Spicer | 4209211 |
| Donaldson | P174675 |
| Fai Filtri | CDK-050-0-3F-A25-A |
| Fleetguard | HF28996 |
| Hydrema | 591050 |
| Manitou | 550145 |
| New Holland (CNH) | 219564A1 |
| New Holland (CNH) | 75286525 |
| New Holland (CNH) | 76086226 |
| New Holland (CNH) | 76094124 |
| New Holland (CNH) | 76094125 |
| New Holland (CNH) | 85806754 |
| Oxfil | HF.7270 |
| Spare Part Mart | SPM-HYD-1169 |
| WIX | 557129 |
| WIX | 57129 |
Found this part cheaper somewhere else? Send us the listing and we'll beat any genuine competitor's price under our Price Beat Guarantee. We continually benchmark the market so you don't have to, so you can buy with confidence knowing you're getting the best available price on Spare Part Mart SPM-HYD-1169.
High-Contaminant Environments
In dusty or dirty operating conditions, the 25 µm inorganic microfibers media efficiently captures particulates, protecting hydraulic components from wear and extending system life.
Continuous-Duty Machinery
For equipment running long shifts, the 10 bar collapse pressure and 1.75 bar bypass valve maintain flow even during pressure spikes, preventing filter bypass and ensuring consistent filtration.
Inventory Consolidation
This single filter cross-references multiple premium brands, allowing workshops to stock one part for Claas, Manitou, and New Holland equipment, reducing inventory complexity and cost.
Preventative Maintenance Programs
With a standard 157.1 mm height and UN 2 inch thread, this filter simplifies scheduled replacements, fitting easily into existing maintenance routines without special tools.
Check your original filter's part number against the cross-references: Baldwin, Claas, Clark Michigan, Dana Spicer, Donaldson, Fai Filtri, Fleetguard, Hydrema, Manitou, New Holland (CNH), Oxfil, or WIX. If your part number matches any of these, SPM-HYD-1169 is a direct replacement.
The filter uses inorganic microfibers media with a 25 µm filtration rating. This media is designed for high dirt-holding capacity and efficient particle capture in hydraulic systems.
It has a UN 2 inch female bottom thread with 16 threads per inch. Total height is 157.1 mm, largest outer diameter is 97 mm, and largest inner diameter is 64 mm. Always verify your housing dimensions before ordering.
No, this is an aftermarket filter built to match OEM specifications. It is a direct replacement for the listed brands, offering the same performance at a lower price.
Installation is straightforward: remove the old filter, clean the mounting surface, lubricate the gasket, and tighten the new filter by hand until the gasket contacts the base, then give an additional 3/4 turn. Do not overtighten.
We offer worldwide shipping with tracking. Your purchase is covered by a 30-day money-back guarantee and a price-beat guarantee to ensure you get the best value.
