| Filtration Media | Impregnated Paper 10 µm |
| Media type | Impregnated Paper |
| Filtration Rating | 10 µm |
| Total Height | 200 mm (7 7/8") |
| Bypass Valve Opening Pressure | 1.75 bar (25 PSI) |
| Smallest Inner Diameter | 28.6 mm (1 1/8") |
| Outer Diameter | 59 mm (2 5/16") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Argo | P3062051 |
| Baldwin | PT9153 |
| Caterpillar | SX9461 |
| Compair-Demag | 76204173 |
| Digoema | DGMH2301 |
| Donaldson | P173486 |
| Epe | 11140P10 |
| Fai Filtri | 025-4-0801 |
| Fleetguard | HF28796 |
| Jungheinrich | 50218875 |
| Omt | PR1002AN |
| Oxfil | OF.8316 |
| Parker Parfit | PR4474 |
| Spare Part Mart | SPM-OIL-1166 |
| ST Separat Tech | ST1319 |
| Still | 142389 |
| Still | 142398 |
| Woodgate | WGH2051 |
Found this part cheaper somewhere else? Send us the listing and we'll beat any genuine competitor's price under our Price Beat Guarantee. We continually benchmark the market so you don't have to, so you can buy with confidence knowing you're getting the best available price on Spare Part Mart SPM-OIL-1166.
Continuous-Duty Hydraulic Systems
In hydraulic systems that run for extended periods, this filter's 10 µm rating captures fine particles that cause wear. The 1.75 bar bypass valve ensures oil circulation even if the filter becomes clogged, preventing system starvation.
Cold-Weather Operation
During cold starts, oil viscosity is high. The bypass valve opens at 1.75 bar to allow oil to flow around the filter element, reducing pressure drop and protecting the engine or hydraulic pump until the oil warms up.
Inventory Consolidation for Mixed Fleets
If your fleet includes equipment from Caterpillar, Donaldson, or Fleetguard, this single aftermarket filter can replace multiple OEM part numbers, simplifying stock management and reducing storage space.
Dusty Construction Environments
In construction sites with high airborne debris, the impregnated paper media traps abrasive particles effectively. The robust construction withstands vibration and pressure spikes common in heavy equipment.
Check your equipment's manual or existing filter for the part number. If it matches any of the cross-referenced brands (Argo, Baldwin, Caterpillar, etc.), this filter is a direct replacement. For Caterpillar machines, it fits models that use the corresponding OEM filter.
The filter uses impregnated paper media with a 10 µm filtration rating. This means it captures particles as small as 10 microns, providing effective protection for engines and hydraulic systems.
The total height is 200 mm, outer diameter is 59 mm, and the smallest inner diameter is 28.6 mm. The bypass valve opens at 1.75 bar. For exact thread size, please measure your existing filter's thread as this is not specified.
Yes, this filter is built to match OEM specifications and is a direct replacement. It uses the same media type and bypass valve pressure, ensuring equivalent performance at a lower cost.
Installation is similar to the OEM filter. Lubricate the gasket with clean oil, screw on by hand until the gasket contacts the mounting surface, then tighten an additional 3/4 turn. Do not overtighten.
