Aftermarket protective window for Precitec laser cutting heads. Replaces Precitec P0595-90154. Size D24.4 x 2 mm, 30 kW. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers.
Fits ProCutter 2.0, ProCutter Zoom 2.0. Sold in packs of 1, 5 or 10.
| Replaces | Precitec P0595-90154 |
| Size | D24.4 x 2 mm, 30 kW |
| Power Rating | 30 kW |
| Material | Fused silica, AR coated both faces |
| Wavelength | 1064 nm |
| Pack Options | 1 pack, 5 pack, 10 pack |
| Pack | Dimensions | Precitec Part No.(SPM Part No.) | Fits |
|---|---|---|---|
| D24.4 x 2 mm, 30 kW | D24.4 x 2 mm, 30 kW | P0595-90154(SPM-LAS-2132) | ProCutter 2.0, ProCutter Zoom 2.0 |
Routine changes
Replace the window when it shows spatter, pitting or burn marks. A dirty window absorbs power and can crack.
Protecting the focusing lens
The window keeps spatter and fume off the focusing lens above it.
Loss of cutting power
If piercing slows or the kerf widens, check the protective window before changing cutting parameters.
Found this part cheaper elsewhere? Send us the listing and we will beat it under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Check the part number on the old window's packaging or your parts list, or measure the diameter and thickness. They must match the size shown.
No. It is an aftermarket window made to the same size. The OEM part number is shown so you can match the window you are replacing.
It is the same window in each. The 10 pack has the lowest price per window.
Hold it by the edge with clean gloves and keep it in its case until fitting. Clean only with lens tissue and optical alcohol.
