| Element Collapse pressure | 16 bar (232 PSI) |
| Filtration Media | Impregnated Paper 10 µm |
| Media type | Impregnated Paper |
| Filtration Rating | 10 µm |
| Flow direction | Out-In |
| Body Height | 304 mm (11 31/32") |
| Bypass Valve Opening Pressure | 2 bar (29 PSI) |
| Largest Inner Diameter | 45 mm (1 25/32") |
| Largest Outer Diameter | 83 mm (3 9/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Fai Filtri | CF-01-E-425-B-P10-NA |
| Internormen | 01E42510P16SP |
| Internormen | 300245 |
| Mann-Filter / Mann & Hummel | HD961 |
| Oxfil | HF.7332 |
| Paus | 50484 |
| Spare Part Mart | SPM-HYD-1104 |
| Stauff | RN100K10B |
| Volvo | 200020439407 |
| Zettelmeyer | 20022834532 |
| Zettelmeyer | 20439407 |
| Zettelmeyer | 22834532 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| FilterFinder Online | USD 73.00 | 11 Oct 2026 |
| Hydrafil | USD 182.95 | 11 Oct 2026 |
| Spare Part Mart | USD 58.41 | Today |
Our price of USD 58.41 is 20% to 68% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
High-Pressure Hydraulic Systems
In systems operating near 16 bar, this element's collapse pressure provides a safety margin against filter clogging, preventing media rupture and downstream contamination.
Continuous-Duty Operations
For machinery running extended shifts, the 10 µm rating captures fine particles that cause wear, extending component life and reducing unplanned downtime.
Cold-Start Environments
The 2 bar bypass valve opens during cold starts when oil is thick, ensuring flow is maintained while still filtering most contaminants once warm.
Inventory Consolidation
With cross-references to multiple brands, this single part number can replace several OEM elements, simplifying stock management for workshops servicing diverse fleets.
Check your existing filter's dimensions: body height 304 mm, largest outer diameter 83 mm, largest inner diameter 45 mm. Also verify the thread or mounting style matches your housing.
It means the filter captures particles larger than 10 micrometres, which is suitable for most hydraulic systems requiring standard cleanliness levels (e.g., ISO 4406 22/18/13).
The element has a largest inner diameter of 45 mm and largest outer diameter of 83 mm. Ensure your housing accepts these sizes and that the sealing surfaces are compatible.
This element is built to the original dimensions and ratings using impregnated paper media. It is a direct replacement but not branded as genuine. It offers similar performance at a lower cost.
Install with flow direction out-in. Ensure the bypass valve is oriented correctly. Replace the element when the differential pressure indicator signals or per your maintenance schedule.
