| Filtration Media | Wire Mesh 50 µm |
| Media type | Wire Mesh |
| Filtration Rating | 50 µm |
| Flow direction | Out-In |
| Total Height | 275 mm (10 13/16") |
| Bypass Valve Opening Pressure | 3 bar (44 PSI) |
| Largest Inner Diameter | 48.5 mm (1 29/32") |
| Smallest Inner Diameter | 46 mm (1 13/16") |
| Largest Outer Diameter | 95 mm (3 3/4") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Fai Filtri | R-0500-S50-NHA |
| Fleetguard-ST | ST1473 |
| Hydac | 0500R050WHC |
| Oxfil | HF.9164 |
| Spare Part Mart | SPM-HYD-1783 |
Found this part cheaper somewhere else? Send us the listing and we'll beat any genuine competitor's price under our Price Beat Guarantee. We continually benchmark the market so you don't have to, so you can buy with confidence knowing you're getting the best available price on Spare Part Mart SPM-HYD-1783.
High-cycle manufacturing lines
Continuous-duty hydraulic machinery in manufacturing environments demands filter elements that resist plugging under steady flow. The wire mesh media handles sustained operation, reducing unplanned downtime from filter changes.
Mobile plant in dusty conditions
Construction and agricultural equipment ingests airborne contaminants. The 50-micron mesh captures abrasive particles before they circulate, protecting cylinder seals and valves in challenging outdoor environments.
Centralised fleet maintenance
When a workshop services multiple Hydac-equipped machines, cross-referencing to one part number consolidates inventory. The filter’s compatibility across several brand codes simplifies stock control and reduces ordering complexity.
High-pressure hydraulic presses
In systems where tight clearances are critical, this element maintains oil cleanliness under load. The integrated bypass valve, set to open at 3 bar, safeguards flow if the media becomes loaded, preventing pressure spikes.
SPM-HYD-1783 is built as a direct replacement for Hydac filters sharing the same dimensions and specifications. It also cross-references with elements from Fai Filtri, Fleetguard-ST and Oxfil. Confirm the measurements against your current housing to ensure a correct match.
The media is a wire mesh with an absolute filtration rating of 50 µm. This means it retains 99.9% of solid particles 50 microns and larger, providing consistent protection for hydraulic components without excessive pressure drop.
Total height is 275 mm, largest outer diameter 95 mm, largest inner diameter 48.5 mm and smallest inner diameter 46 mm. The element follows an Out-In flow direction. These values are critical for sealing correctly in the filter bowl.
It is manufactured to match the form, fit and function of the original Hydac design. The wire mesh media and bypass valve specifications are engineered to deliver equivalent performance, giving you a reliable, lower-cost alternative for routine servicing.
Always isolate and depressurise the system before opening the filter housing. Replace the element according to the machine’s service manual, ensuring the O-rings are lubricated. The bypass valve cracks open at 3 bar to maintain flow if the element becomes restricted.
