| Burst Pressure | 21 bar (305 PSI) |
| Element Collapse pressure | 10 bar (145 PSI) |
| Filtration Media | Wire Mesh 60 µm |
| Media type | Wire Mesh |
| Filtration Rating | 60 µm |
| Total Height | 209 mm (8 7/32") |
| Thread | GAS 3/4 inch Female Bottom |
| Type | GAS |
| Thread Size | 3/4 inch |
| Orientation | Female |
| Position | Bottom |
| Bypass Valve Opening Pressure | 1.75 bar (25 PSI) |
| Working Pressure | 12 bar (174 PSI) |
| Outer Diameter | 96 mm (3 25/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Donaldson | CAR806 |
| Donaldson | P171632 |
| Fai Filtri | CTT-070-0-3-M60-A |
| Filtrec | A211T60BM |
| Omt | CSM06CNR |
| Oxfil | OF.8829 |
| Sofima (UFI) | CA152EMS1M |
| Sofima (UFI) | CCA152EMS1M |
| Sofima (UFI) | CCA152MS1BM |
| Spare Part Mart | SPM-OIL-1388 |
| Stauff | SFCT3660ER |
Found this part cheaper somewhere else? Send us the listing and we'll beat any genuine competitor's price under our Price Beat Guarantee. We continually benchmark the market so you don't have to, so you can buy with confidence knowing you're getting the best available price on Spare Part Mart SPM-OIL-1388.
High-pressure hydraulic circuits
In systems operating near 12 bar continuously, the filter's robust construction and 21 bar burst rating prevent failures, safeguarding expensive pumps and motors.
Contaminant-heavy environments
On construction sites or in forestry, the 60 µm wire mesh captures dirt and metal particles, extending the life of hydraulic components and reducing unscheduled downtime.
Fleet maintenance consolidation
For workshops servicing multiple brands that specify the same OEM filter, this cross-compatible unit simplifies inventory and lowers per-unit cost without sacrificing fit or performance.
Scheduled maintenance programmes
The quick-change spin-on design allows service technicians to replace filters rapidly during routine servicing, keeping equipment in operation and meeting maintenance intervals.
Yes, this filter is a direct replacement for Donaldson oil filters, as well as those from Fai Filtri, Filtrec, Omt, Oxfil, Sofima (UFI), and Stauff. It matches critical dimensions and thread type. Always confirm your housing specifications via the part number cross-reference.
It has a 60 µm absolute rating using wire mesh media. This provides a balance between particle removal and flow resistance for most hydraulic and lubrication applications.
The filter has a total height of 209 mm, an outer diameter of 96 mm, and a GAS 3/4 inch female bottom thread. Ensure your filter head has matching clearance and thread before ordering.
This filter is an aftermarket filter manufactured to the same form and functional standards as the OEM versions. It is a cost-effective alternative, not a genuine OEM part, but it is backed by our 30-day guarantee for peace of mind.
Clean the mounting surface, lubricate the gasket with fresh oil, and spin the filter on by hand until the gasket contacts the base. Then tighten to the specified torque, typically an additional half to three-quarter turn. Always prime the system and check for leaks after startup.
