| Burst Pressure | 17 bar (247 PSI) |
| Element Collapse pressure | 10 bar (145 PSI) |
| Filtration Media | Wire Mesh 60 µm |
| Media type | Wire Mesh |
| Filtration Rating | 60 µm |
| Total Height | 226 mm (8 29/32") |
| Thread | GAS 1.1/4 inch Female Bottom |
| Type | GAS |
| Thread Size | 1.1/4 inch |
| Orientation | Female |
| Position | Bottom |
| Bypass Valve Opening Pressure | 1.75 bar (25 PSI) |
| Working Pressure | 12 bar (174 PSI) |
| Outer Diameter | 127 mm (5") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Donaldson | CAR2006 |
| Donaldson | P171642 |
| Fai Filtri | CTT-150-0-3-M60-A |
| Filtrec | A221T60BM |
| Omt | CSM15CNR |
| Oxfil | OF.8850 |
| Sofima (UFI) | CA302EMS1M |
| Sofima (UFI) | CA302MS1BM |
| Sofima (UFI) | CCA302EMS1M |
| Sofima (UFI) | CCA302MS1BM |
| Spare Part Mart | SPM-OIL-1405 |
| Stauff | SFCT5860ER |
Found this part cheaper somewhere else? Send us the listing and we'll beat any genuine competitor's price under our Price Beat Guarantee. We continually benchmark the market so you don't have to, so you can buy with confidence knowing you're getting the best available price on Spare Part Mart SPM-OIL-1405.
High-Dust Operating Environments
Wire mesh media withstands heavy particulate loading without rapid plugging. The 60 micron rating captures harmful contaminants while allowing operators to clean and reuse the element, reducing downtime and replacement costs in dusty yards or remote sites.
Frequent Cold-Start Cycles
The 1.75 bar bypass valve ensures immediate oil flow to critical components when viscosity is high. This prevents dry starts and protects pumps and bearings, extending equipment life in cold climates or intermittent-duty machinery.
Fleet Standardisation
Consolidating filter stocks with a single aftermarket option that matches multiple branded equivalents simplifies inventory management for maintenance teams. This filter covers several common housings, reducing part numbers and procurement complexity.
High-Flow Lubrication Circuits
Engineered for minimal pressure drop, the wire mesh construction maintains oil flow rates in demanding hydraulic systems. This supports consistent actuator speed and cooling, preventing performance loss even as the element traps debris.
This this filter element is a direct dimensional replacement for the specified Donaldson cross-reference, as well as filters from Fai Filtri, Filtrec, Omt, Oxfil, Sofima (UFI), and Stauff. Confirm that your housing accepts a GAS 1.1/4 inch female thread, 127 mm OD, and 226 mm overall height.
It has a nominal rating of 60 micron using wire mesh media. The mesh is cleanable and reusable in many applications, offering consistent particle retention with high dirt-holding capacity for hydraulic and lubrication oils.
The filter features a GAS 1.1/4 inch female thread on the bottom. Total height is 226 mm and outer diameter is 127 mm, matching common spin-on housings from the listed cross-reference brands.
It is an aftermarket filter, not a branded OEM item. It is built to match the dimensional and performance specifications of the cross-referenced elements so you get equivalent filtration without paying for the brand name.
Follow the service schedule recommended by your equipment manufacturer. Because the media is wire mesh, the element can often be cleaned, inspected, and reused several times before replacement is necessary.
SPM provides a 30-day money-back guarantee and a price-beat guarantee on this item. We ship worldwide with full tracking on every order.
