Powder-Free Anti-Static Finger Cots for Handl...: High voltage power supply for a 100 W class CO2 glass laser tube. It takes AC 220V mains and drives the tube at up to 40 kV and 28 mA, with the output current set by the machine controller through the IN (0 to 5 V or PWM) input.
This is the DY13 pattern: 270 x 163 x 85 mm, about 2.6 kg, fan cooled, with a six way control terminal (5V out, active high and active low laser enable, water protection, ground, 0 to 5 V power input), a TEST button and a screw terminal for the AC input. The DY series is the supply RECI matches to its W2 and S2 tubes, so it is the usual like-for-like swap on machines built around a RECI tube.
A failing supply shows up as weak or unstable cutting, a tube that will not fire although the TEST button is pressed, or a supply that trips or clicks under load. Check the tube and the water protection switch first: a supply that fires the tube on TEST but not from the controller usually has a wiring or enable signal fault, not a dead supply.
| Type | CO2 laser tube high voltage power supply |
| Pattern | DY13 |
| Rated power | 100 W |
| Matching tube | 80 to 100 W (RECI W2, S2 and Z2 class) |
| Input | AC 220V single phase, 50/60 Hz |
| Max output voltage | 40 kV |
| Max output current | 28 mA |
| Power control | IN terminal, 0 to 5 V analog or PWM |
| Laser enable | Active high or active low enable input |
| Water protection | WP input: the supply will not fire unless the flow switch closes |
| Dimensions | 270 x 163 x 85 mm (10 5/8 x 6 3/8 x 3 3/8 in) |
| Weight | About 2.6 kg (5.7 lb) |
| Cooling | Built-in fan |
| Sold as | Single power supply with high voltage lead |
| Country of Manufacture | China |
100 W class CO2 laser tubes
Match the supply to the tube rating, not the machine name: a supply far above the tube rating can overdrive it, one below it limits power. This listing is the 220V version; machines on 110 to 120 V mains need the 110V version, so ask us before ordering.
| Dimensions | Part No.(SPM Part No.) |
|---|---|
| 270 x 163 x 85 mm, 100 W | Standard pattern(SPM-CO2-1009) |
Replacing a failed supply
When the tube is known to be good and the supply no longer fires it, a like-for-like supply restores the machine without rewiring.
Keeping a spare
A supply failure stops the machine. A spare on the shelf turns a week of downtime into an hour of swapping two plugs and the high voltage lead.
Fitting a new tube
When a tube is replaced with a 100 W class tube, the supply should match it. Running a tube near the supply's maximum current shortens tube life.
Upgrading a tired machine
Older supplies drift and lose regulation. A new supply gives steadier current, which shows as more even cut depth and engraving tone.
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| Cloudray (DY13, 230V) | USD 155.00 | 17 Oct 2026 |
| eBay (5 aftermarket sellers) | USD 190.79 to 241.54 | 17 Oct 2026 |
| Spare Part Mart | USD 124.00 | Today |
Our price of USD 124.00 is 20% to 49% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Check the tube rating on its label. This supply is for 80 to 100 W (RECI W2, S2 and Z2 class) tubes, with a maximum of 28 mA. Run the tube at or below the current its maker recommends, usually well under the supply maximum.
No. It is an aftermarket supply built to the same pattern, terminals and ratings as the original. We do not claim it is made by the original brand.
No. This listing is the AC 220V version. For 110 to 120 V mains, contact us before ordering and we will quote the 110V version.
AC mains to the input terminal, the high voltage lead to the tube anode (positive) end, the tube cathode return to the supply, the water flow switch to WP and G, and the controller's enable and power signals to the control terminal. Earth the case.
The output reaches tens of kilovolts. Switch off and unplug the machine, wait several minutes and discharge the tube lead before touching any connection. If you are not sure, have a technician fit it.
The water flow switch, the lid interlock, the tube itself and the enable wiring. Many supplies are replaced when the fault was a stuck flow switch.
