Aftermarket 3D ceramic nozzle holder for BOCI (Bochu) laser cutting heads. Replaces BOCI DY.C.A0004AA, the small white ceramic with the M8 x 0.75 nozzle thread.
This is the slim ceramic used where the head works close to the part: 3D, bevel and tube cutting. It is 20 mm across and 28 mm high, with a three hole top face and a gold plated thread insert for M8 x 0.75 nozzles. Like every ceramic it insulates the nozzle for the capacitive height sensor and breaks first in a collision.
It fits BOCI heads with the M8 x 0.75 3D nozzle mount. Sold in packs of 1, 5 or 10.
| Replaces | BOCI DY.C.A0004AA |
| Diameter | 20 mm |
| Height | 28 mm |
| Nozzle Thread | M8 x 0.75 |
| Top Face | Three hole |
| Colour | White |
| Material | Technical ceramic with gold plated thread insert |
| Use | 3D, bevel and tube cutting heads |
| Pack Options | 1 pack, 5 pack, 10 pack |
| Stat. HS-Code | 846693 |
BOCI cutting heads
No complete head list is published for this ceramic. It fits BOCI heads that take M8 x 0.75 nozzles on the D20 ceramic: measure the old one (20 mm across, 28 mm high, M8 thread) or match the part number.
| Pack | Dimensions | BOCI Part No.(SPM Part No.) | Fits |
|---|---|---|---|
| D20 x H28 mm, M8 | D20 x H28 mm, M8 | DY.C.A0004AA(SPM-LAS-2243) | BOCI BLT heads with the M8 x 0.75 3D nozzle mount |
After a head collision
A crash into a tipped up part usually breaks the ceramic first, which protects the rest of the head. A spare on the shelf gets the machine cutting again within minutes.
Height sensing faults
A cracked ceramic, a loose thread or a burned contact pin upsets the capacitive height control, so the head hunts, stops with a sensor alarm or touches the sheet. Replace the ceramic before chasing the sensor.
Nozzle will not centre or sit square
A worn or damaged thread in the ceramic lets the nozzle sit off centre, which shows as uneven cut quality in different directions.
Planned maintenance
Check the ceramic at every nozzle change and replace it when it is chipped, cracked, discoloured or loose.
| Seller | Price | Checked |
|---|---|---|
| Cloudray, aftermarket (cheapest, BOCI Series Laser Cutting Ceramics D20 H28 M8) | USD 15.90 | checked 4 Oct 2026 |
| eBay, aftermarket ('BOCI Laser Cutting Ceramic Ring D20 M8') | USD 16.08 | checked 4 Oct 2026 |
| Spare Part Mart (aftermarket) | USD 12.72 | this page |
Compared with other aftermarket sellers of the same ceramic, our single piece price is 20% to 21% less. Prices are in US dollars for one piece, as listed on the date shown. The 5 and 10 packs cost less per piece.
Found this part cheaper elsewhere? Send us the listing and we will beat it under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Check for DY.C.A0004AA in your parts list, or measure the old ceramic: 20 mm across, 28 mm high, with an M8 x 0.75 nozzle thread. The D41 ceramic (Y.Z.C0034) is for 2D sheet cutting heads.
No. It is an aftermarket ceramic made to the same size and thread. It is not made by or affiliated with BOCI (Bochu); the BOCI part number is shown only so you can match the part you are replacing.
It is the same ceramic in each. The 10 pack has the lowest price per piece and suits shops that crash a head now and then or run several machines.
Yes. After changing the ceramic, fit the nozzle, run the capacitive height sensor calibration on the controller and check the nozzle centring before cutting.
