- SKU: SPM-SEP-1267
- Verfügbarkeit:
Quincy 1630390414 Aftermarket Separator
$58.78 USD
Aktuelle Versandkosten siehe unten.
- Produktart: Separator
- Barcode:
Quincy 1630390414, direct aftermarket replacement. This aftermarket oil separator element is a drop-in replacement designed for the Atlas Copco GHS 350 VSD rotary screw compressor. Engineered to match OEM filtration performance, it reliably removes oil mists from compressed air, helping protect downstream equipment and maintain air quality. With an outer diameter of 95 mm, a total height of 370 mm, and a net weight of just 0.42 kg, this separator fits directly into the existing housing without modification. Its precise dimensions and robust construction ensure a secure seal and consistent separation efficiency. Choosing this Spare Part Mart alternative gives you OEM-relevant performance at a fraction of the cost, backed by our 30-day money-back guarantee and price-beat promise. It also cross-references to elements from HiFi Filter, Noitech, Oxfil, and Quincy, simplifying stock management if you operate multiple brands.
TECHNICAL PROPERTIES & CROSS REFERENCES
Specifications
| Height-1 | 334 mm (13 1/8") |
| Total Height | 370 mm (14 9/16") |
| Product Net Weight | 0.42 kg (0.93 lbs) |
| Smallest Inner Diameter | 45 mm (1 25/32") |
| Outer Diameter | 95 mm (3 3/4") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
Compatible Equipment
Atlas Copco
GHS 350 VSD
Cross References
| Brand | Code |
|---|---|
| Atlas Copco | 1625.3902.74 |
| Atlas Copco | 1625.3902.96 |
| Atlas Copco | 1625390274 |
| Atlas Copco | 1625390296 |
| Atlas Copco | 1630.3904.94 |
| Atlas Copco | 1630390494 |
| HiFi Filter | OA 1263 |
| Noitech | NS 100239 |
| Oxfil | SP.4930 |
| Quincy | 1625390414 |
| Quincy | 1630390414 |
| Spare Part Mart | SPM-SEP-1267 |
Price Beat Guarantee
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Use Cases & Applications
Reliable Separation in High-Temperature Environments
When a compressor runs in a hot plant room or during peak summer conditions, oil carryover can spike. This separator is built to maintain high separation efficiency even under thermal stress, reducing oil consumption and keeping air lines cleaner.
Continuous-Duty Operations
For facilities that run their GHS 350 VSD around the clock, unplanned downtime is costly. This separator delivers the durability needed for 24/7 cycles, helping you stick to scheduled maintenance intervals and avoid emergency call-outs.
Consolidating Multi-Brand Fleets
If your workshop houses compressors from different manufacturers but uses similar separator elements, cross-referencing to HiFi Filter, Noitech, Oxfil, and Quincy means you can standardise on one reliable aftermarket part, simplifying inventory and reducing future ordering complexity.
Cost-Effective Fleet Maintenance
Equipping multiple compressors with OEM separators can quickly strain the maintenance budget. This separator delivers comparable oil separation performance at a lower price point, allowing you to refresh all machines on schedule without overspending.
Frequently Asked Questions
Will this separator fit my Atlas Copco GHS 350 VSD compressor?
Yes, this separator is a direct physical replacement for the original separator element in the GHS 350 VSD. With an outer diameter of 95 mm, a total height of 370 mm, and a smallest inner diameter of 45 mm, it slots straight into the existing housing.
What is the filtration efficiency or micron rating of this element?
As an aftermarket component, we build this separator to replicate the oil separation performance of the OEM part. While we do not publish a specific micron rating, the media and design target the same oil carryover levels required by the GHS 350 VSD, ensuring your compressed air remains clean.
Are the thread and mounting dimensions identical to the OEM part?
Every critical dimension is matched to the original. The outer diameter is 95 mm, total height 370 mm, height-1 334 mm, and the smallest inner diameter is 45 mm. The element drops in with a precise fit, and the sealing surfaces are engineered to prevent bypass.
Is this a genuine Atlas Copco part?
No, this is an aftermarket separator supplied by Spare Part Mart. It is not a genuine Atlas Copco component but is built to the OEM specifications for the GHS 350 VSD. We back it with a 30-day money-back guarantee and our price-beat promise, giving you confidence in its quality and performance.
Can I install this separator myself, or do I need special tools?
Installation follows the standard procedure for the GHS 350 VSD separator element. No special tools are required beyond basic hand tools. Always depressurise the compressor and follow the machine's service manual. If you are unfamiliar, a qualified technician should perform the replacement.
What delivery options and guarantees come with this product?
We ship worldwide with full tracking. Your purchase is covered by our 30-day money-back guarantee, and if you find the same element cheaper elsewhere, we will beat that price. Terms apply, see our website for full details.
Bilder und Daten dienen als Richtlinie und werden von Spare Part Mart als zuverlässig erachtet. Das Produkt kann abweichen (z. B. Farbe), entspricht jedoch den oben genannten Spezifikationen. Alle Querverweise werden nach unserem besten Wissen als zuverlässig erachtet. Wir empfehlen Ihnen, vor der Bestellung eine Überprüfung vorzunehmen.
