| Part Type | Filter element |
| Replaces | Argo-Hytos V3.0817-26 (also written V3081726) |
| Filtration Media | Pleated stainless steel wire mesh |
| Filtration Rating | 60 µm, Argo-Hytos 26 wire mesh grade |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR) |
| Largest Outer Diameter | 79 mm (3 1/8") |
| Largest Inner Diameter | 40.8 mm (1 19/32") |
| Total Height | 170 mm (6 11/16") |
| Series | V3.0817 |
| End Configuration | Single open end, O-ring seal |
| Collapse Rating | 30 bar (450 psid) |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Argo | V3.0817-26 |
| Spare Part Mart | SPM-HYD-2448 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-41% on Argo V3.0817-26 buying from SPM.
Return and transfer lines
The 60 µm mesh grade catches wear debris and scale on return and transfer lines without the pressure drop of a glass fibre element.
Lube oil and gearbox circuits
Mesh elements suit lubrication circuits on gearboxes and pumps, where coarse protection is all the circuit needs.
Mobile and industrial hydraulics
Argo-Hytos filters taking V3.0817 elements are fitted to mobile machines and industrial power units; the mesh grade is the one for coarse duty.
Cleanable elements
Stainless mesh elements can be washed and refitted, so a site can keep one spare in rotation while the other is cleaned.
No. It is an aftermarket element made to the dimensions and grade of the Argo-Hytos V3.0817-26. It is not made by or affiliated with Argo-Hytos, and the Argo-Hytos part number is used only to show what it replaces.
Yes if your filter takes the Argo-Hytos V3.0817-26. Check the old element: 79 mm outside diameter, 40.8 mm bore and 170 mm overall length.
Argo-Hytos uses the digits after the dash for the media grade. 26 is the 60 µm stainless steel wire mesh grade. Glass fibre grades of the same element end in 03, 06, 16 or 18.
Yes. Stainless mesh elements can be washed in clean solvent and blown out from the inside, then refitted if the mesh is undamaged. Replace it once it no longer cleans up or the pleats are damaged.
Nitrile (NBR) O-ring seals, which suit mineral oil based hydraulic fluids. Ask us before ordering if your system runs a fire resistant or synthetic ester fluid.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
