| Part Type | Hydraulic filter element |
| Replaces | Bystronic 81100.0000.0098 / Hydac 0240D010BH4HC / Hydac 1253074 |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 10 µm |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR) |
| Largest Outer Diameter | 69.1 mm (2 23/32") |
| Largest Inner Diameter | 34.3 mm (1 11/32") |
| Total Height | 174 mm (6 27/32") |
| Construction | Single open end, steel end caps and support tube |
| Collapse Rating | 210 bar (3,045 psid), high collapse |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Bystronic | 81100.0000.0098 |
| Hydac | 0240D010BH4HC |
| Hydac | 1253074 |
| Spare Part Mart | SPM-HYD-3137 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| SONA Filtration | USD 90.10 | 8 Oct 2026 |
| Hydrafil | USD 228.95 | 8 Oct 2026 |
| Spare Part Mart | USD 72.08 | Today |
Our price of USD 72.08 is 20% to 69% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Bystronic press brakes
The hydraulic unit of a Bystronic press brake runs both main cylinders through proportional valves. Clean oil keeps the ram parallel and the bending angle repeatable, so the element is changed at every service.
Bending shops with several machines
Shops running more than one Xpert can keep elements on the shelf and change them at the planned service instead of waiting for a dealer delivery.
After a valve or pump repair
Fit a new element after any hydraulic repair to catch the debris the work leaves in the system.
Industrial power units
The same element size is used on other machine tool and press hydraulic units fitted with the same filter housing.
No. It is an aftermarket element made to the dimensions and filtration grade of the Bystronic 81100.0000.0098 / Hydac 0240D010BH4HC / Hydac 1253074. It is not made by or affiliated with Bystronic or the filter maker, and the part number is used only to show what it replaces.
Yes if your filter takes the Bystronic 81100.0000.0098 / Hydac 0240D010BH4HC / Hydac 1253074. Check the old element: 69.1 mm outside diameter, 34.3 mm bore and 174 mm overall length.
No. This element is for the Xpert 250 and Xpert 320 with the ByVision touch screen. Xpert machines with the MMC or Cybelec control use the Rexroth element (Bystronic 81100.0000.0046), and the Xpert Pro uses a different filter.
Nitrile (NBR) seals, which suit mineral oil based hydraulic, lube and turbine oils. Ask us before ordering if your system runs a fire resistant or synthetic ester fluid.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
