| Part Type | Compressed air filter element |
| Replaces | Deltech HFD750 |
| Element Size | 750 |
| Grade | grade HFD (high efficiency coalescing, 0.01 micron) |
| Filtration | Particles down to 0.01 micron including oil aerosols, about 0.01 mg/m3 residual oil (ISO 8573-1 class 1) |
| Outside Diameter | 118 mm (4-5/8 in) |
| Height | 666 mm (26-1/4 in) |
| Rated Flow | 1,558 scfm (2,500 Nm3/h) at 7 bar (100 psi) |
| Flow Direction | Inside to outside |
| Max. Operating Pressure | 16 bar (232 psi) |
| Stat. HS-Code | 842139 |
| Brand | Code |
|---|---|
| Deltech | HFD750 |
| Spare Part Mart | SPM-INF-3038 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| eBay (2 aftermarket sellers) | USD 211.44 to 390.50 | 7 Oct 2026 |
| Moisture Boss | USD 339.57 | 7 Oct 2026 |
| Filme Compressor | USD 504.00 | 7 Oct 2026 |
| Air Compressor Services | USD 1,634.50 | 7 Oct 2026 |
| Spare Part Mart | USD 169.15 | Today |
Our price of USD 169.15 is 20% to 90% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Annual element change
Change DFD, PFD and HFD elements at least once a year, or sooner when the pressure drop across the filter reaches about 350 mbar (5 psi). Change CFD carbon elements at least every 6 months.
Instrument and process air
The HFD stage brings oil aerosols down to the level needed for instrument air, paint lines, packaging and air dryers.
Workshop and plant air
Line filters sit after the compressor, receiver or dryer to keep water, oil and dirt out of air tools, valves and cylinders.
No. It is an aftermarket compressed air filter element made to replace the Deltech HFD750. It is not made by or affiliated with Deltech or SPX, and the part number is used only to show what it replaces.
It replaces the element marked HFD750. Check the code printed on the old element, or measure it: this one is 118 mm (4-5/8 in) in diameter and 666 mm (26-1/4 in) high. The letters give the grade (DFD dry particulate, PFD general purpose, HFD high efficiency, CFD carbon) and the number is the size.
Change DFD, PFD and HFD elements at least once a year, or sooner when the pressure drop across the filter reaches about 350 mbar (5 psi). Change CFD carbon elements at least every 6 months.
Use the same letters as the element you are taking out. A typical line runs PFD then HFD after the compressor, CFD after that when oil vapour and odour must be removed, and DFD after a desiccant dryer to stop dust.
Change the other elements in the same line at the same service, fit new O-rings if the old ones are flattened or cracked, and check that the drain on the filter bowl works.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
Prices depend on your postcode.
In USD for the quantity selected. The exact cost is confirmed at checkout.
