| Element Collapse pressure | 20 bar (290 PSI) |
| Filtration Media | Inorganic Microfibers 12 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 12 µm |
| Flow direction | Out-In |
| Total Height | 483 mm (19") |
| Bypass Valve Opening Pressure | 3 bar (44 PSI) |
| Largest Inner Diameter | 96.5 mm (3 13/16") |
| Smallest Inner Diameter | 95.5 mm (3 3/4") |
| Outer Diameter | 143 mm (5 5/8") |
| Largest Outer Diameter | 143.5 mm (5 21/32") |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Airfil | AFPOVL28010 |
| Behringer | BE1300R12A43 |
| Behringer | BE1300R12AR43 |
| Comex | H1300RN10 |
| Comex | H1300RN2010 |
| Compair-Demag | 97357373 |
| Donaldson | HR130002 |
| Donaldson | P170620 |
| Donaldson | P566999 |
| Donaldson | P570313 |
| Epe | 101300H10SL0006P |
| Epe | 101300LAH10SL0006P |
| Epe | 101300LAH10SL0006PX |
| Epe | 101300LAH10SL006P |
| Epe | 101300LAH10XL006M |
| Epe | E30TR1300H10 |
| Epe | E30TR1300H10LLLA |
| Fai Filtri | R-1300-A10-NHA |
| Fleetguard | HF6856 |
| Fleetguard | ST1162 |
| Hy-Pro | HP95RNL1812MB |
| Hy-Pro | HP95RNL1812MSB |
| Hydac | 1263053 |
| Hydac | 1300R010BN |
| Hydac | 1300R010BN3HC |
| Hydac | 1300R010BN4HC |
| Hydac | 1300R010BNHC |
| Hydac | 2059111 |
| Internormen | 0201300R10VG30HCSP |
| Internormen | 0201300R10VG30SP |
| Internormen | 310559 |
| Mahle | 8377798 |
| Mahle | 890018SMX10 |
| Mahle | 890033SMX10 |
| Mann-Filter / Mann & Hummel | HD10158 |
| Mann-Filter / Mann & Hummel | HD101583 |
| Oxfil | HF.9289 |
| Pall | HC2295FKS18H |
| Pall | HC2296FKS18H50 |
| Parker Parfit | 934236 |
| Parker Parfit | 938303Q |
| Parker Parfit | GO3356 |
| Parker Parfit | GO3360 |
| Sandretto | 22601200 |
| Schroeder | SBF1300RZ10B |
| Spare Part Mart | SPM-HYD-1822 |
| ST Separat Tech | H130R10N |
| ST Separat Tech | H300R10N |
| ST Separat Tech | ST2118 |
| Stauff | RE300E10B |
| Stauff | RE300G10B |
| Woodgate | WGHH13010RB |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Continuous-Duty Hydraulic Systems
Keep production machinery running around the clock with a filter built for endurance. The 20-bar collapse pressure and integrated bypass valve ensure flow is never completely blocked, preventing unexpected downtime in 24/7 operations.
Fine Particle Removal in Dusty Environments
When hydraulic systems operate near construction, mining, or agricultural dust, the 12-micron inorganic microfibre media traps fine particles that would otherwise accelerate pump and valve wear. This extends fluid life and component longevity.
Consolidated Fleet Maintenance
If you service a mixed fleet using filters from multiple brands like Donaldson, Parker, or Hydac, this single part number reduces inventory complexity. One aftermarket element replaces many different branded boxes on your shelf.
Preventive Maintenance Scheduling
With a price point that makes regular changes economical, you can stick to tighter service intervals. Switching elements more often based on oil analysis becomes a budget-friendly strategy to protect expensive hydraulic components.
Cross-check the dimensions (483 mm total height, 143 mm outer diameter, 95.5-96.5 mm inner diameter) and the cross-reference list. If your current filter matches one of the brands listed, such as Hydac, Mahle, or Donaldson, this filter is a direct drop-in replacement.
The element uses inorganic microfibre media with an absolute filtration rating of 12 microns. This media captures fine metallic and silt particles that circulate in hydraulic oil, helping to maintain ISO cleanliness codes.
This filter is a cartridge-style element without integral threads. It seats into a hydraulic filter housing using the stated diameters and height. Verify that your housing internal dimensions match the largest OD of 143.5 mm and inner diameters of 95.5-96.5 mm.
No, this is a quality aftermarket filter built to match OEM specifications. It is not manufactured or endorsed by Hydac or any other original equipment maker. You get equivalent filtration performance at a significantly lower cost.
Always depressurise the hydraulic system and allow the oil to cool before opening the housing. Remove the old element, clean the bowl, lubricate the new O-ring seals with clean oil, and insert this filter. Follow your equipment manual for bleeding and restart procedures.
