| Burst Pressure | 55 bar (798 PSI) |
| Element Collapse pressure | 15 bar (218 PSI) |
| Filtration Media | Inorganic Microfibers 25 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 25 µm |
| Total Height | 295 mm (11 5/8") |
| Thread | UN 1.3/4 inch Female Bottom 12 |
| Type | UN |
| Thread Size | 1.3/4 inch |
| Orientation | Female |
| Position | Bottom |
| Working Pressure | 25 bar (363 PSI) |
| Outer Diameter | 117 mm (4 19/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Baldwin | BT8401MPG |
| Donaldson | P171276 |
| Fai Filtri | CSD-400-0-0-A25-V |
| Oxfil | OF.8664 |
| Parker Parfit | 944045Q |
| Spare Part Mart | SPM-OIL-1330 |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
High-Dust Environments
In mining, quarrying or agricultural operations where airborne debris is constant, the inorganic microfibers media provides superior dirt-holding capacity. This reduces the frequency of filter changes and keeps engines cleaner for longer.
Continuous-Duty Machinery
For generators, compressors or pumps running around the clock, this filter maintains consistent oil cleanliness under sustained pressure. Its collapse-resistant element prevents oil starvation even during cold starts.
Preventive Maintenance Routines
Standardised outer diameter and thread dimensions make it a drop-in replacement during scheduled servicing. Technicians can swap it quickly, minimising equipment downtime and labour effort.
Fleet Inventory Simplification
Because it cross-references several major filter brands, you can consolidate inventory to a single part number. This reduces confusion and ordering errors across mixed-equipment fleets.
Compare the dimensions and thread specification to your current filter. This filter has a total height of 295 mm, an outer diameter of 117 mm, and a female UN 1.3/4 inch bottom thread. It cross-references Baldwin, Donaldson, Fai Filtri, Oxfil and Parker Parfit numbers. If your existing filter shares these measurements and cross-references, compatibility is assured.
It uses inorganic microfibers media with a 25-micron absolute rating. This captures microscopic metal particles and soot that would otherwise accelerate engine and hydraulic system wear.
Total height is 295 mm, outer diameter is 117 mm, and the thread is UN 1.3/4 inch, female orientation, located at the bottom. Ensure these match your filter housing before ordering.
It is built to match OEM specifications for form, fit and function. You receive the same 25-micron filtration, pressure ratings and construction quality at a lower cost, without compromising equipment protection.
It is a spin-on filter. Remove the old filter, clean the sealing surface on the housing, apply a film of clean oil to the new gasket, then spin it on and tighten by hand. After starting the engine, check for leaks around the seal.
We ship worldwide with tracking. All orders are covered by a 30-day money-back guarantee. If you find a lower advertised price elsewhere, our price-beat guarantee ensures you pay the best available price.
