| Filtration Media | Inorganic Microfibers 5 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 5 µm |
| Flow direction | Out-In |
| Total Height | 257 mm (10 1/8") |
| Largest Inner Diameter | 47.5 mm (1 7/8") |
| Largest Outer Diameter | 83 mm (3 9/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Airfil | AFKOVL2943 |
| Behringer | BE5001003A |
| Comex | M0030DN2003 |
| Comex | M0030DN3 |
| Donaldson | P174295 |
| Fai Filtri | CF-130-A03-NA |
| Finn Filter | FC5013F003BS |
| Finn Filter | FC5013Q003BS |
| Fleetguard | ST1517 |
| Hy-Pro | HP800L103M |
| Hydac | 1269153 |
| Hydac | 2100D03BN |
| Hydac | 2300D03BN |
| Internormen | 04PI21303VG16EO |
| Internormen | 300815 |
| Mahle | 9640513150 |
| Mahle | PI2130SMX3 |
| Mann-Filter / Mann & Hummel | HD9523 |
| Oxfil | HF.7484 |
| Pall | HC2235FKP10H |
| Parker Parfit | 935241 |
| Parker Parfit | GO2862 |
| Parker Parfit | PR2862 |
| PTI | PG080GH |
| Sofima (UFI) | SPI2030FT11 |
| Spare Part Mart | SPM-HYD-1218 |
| Stauff | SL090E03B |
| Woodgate | WGH9959 |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
High-Pressure Hydraulic Systems
In high-pressure hydraulic circuits, maintaining fluid cleanliness is critical. The 5 µm inorganic microfibers media traps fine particles that can cause valve sticking or pump wear, extending component life and reducing unplanned downtime.
Continuous-Duty Industrial Equipment
For machinery running 24/7, such as injection molding presses or metal forming machines, this filter provides consistent filtration performance. Its robust construction handles steady flow rates without bypass, ensuring long service intervals.
Mobile Hydraulics in Construction
Construction equipment like excavators and loaders operate in dusty environments. The out-in flow design and 5 µm rating prevent dirt ingress from contaminating the hydraulic fluid, safeguarding cylinders and pumps from abrasive wear.
Inventory Consolidation for Hydac Systems
Facilities with multiple Hydac-equipped machines can standardize on this filter. Its single part number replaces several OEM references, simplifying stock management and reducing the risk of using the wrong filter.
Check your current filter's part number against the cross-reference list. Alternatively, measure the total height (257 mm), largest outer diameter (83 mm), and largest inner diameter (47.5 mm) to ensure dimensional compatibility.
This filter uses inorganic microfibers media with a 5 µm filtration rating, providing fine particulate removal for hydraulic systems.
Total height is 257 mm, largest outer diameter is 83 mm, and largest inner diameter is 47.5 mm. The flow direction is out-in (outside-to-inside).
This is an aftermarket filter built to match OEM specifications. It is a direct replacement for Hydac and other branded filters, offering equivalent performance at a lower cost.
Installation is straightforward: remove the old filter, clean the housing, lubricate the gasket, and screw in the new filter hand-tight. Follow your equipment manual for specific torque values.
We offer worldwide shipping with tracking. Your purchase is covered by a 30-day money-back guarantee and a price-beat guarantee.
