| Filtration Media | Wire Mesh 25 µm |
| Media type | Wire Mesh |
| Filtration Rating | 25 µm |
| Flow direction | Out-In |
| Total Height | 157 mm (6 3/16") |
| Largest Inner Diameter | 22.1 mm (7/8") |
| Largest Outer Diameter | 44.5 mm (1 3/4") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Epe | E400HL110G25 |
| Fai Filtri | D-0110-S25-NA |
| Fleetguard | ST1060 |
| Hy-Pro | HP06DNL725WSB |
| Hydac | 0110D025W |
| Hydac | 304002 |
| Internormen | 020110D25G30EP |
| Internormen | 300837 |
| Mahle | 7888696 |
| Mann-Filter / Mann & Hummel | HD5102 |
| Oxfil | HF.8696 |
| Parker Parfit | GO3072 |
| Spare Part Mart | SPM-HYD-1688 |
| ST Separat Tech | H110D25W |
| Stauff | SE030B25B |
| Stauff | SE030S25B |
| Woodgate | WGHH11025DW |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Dusty or Dirty Environments
The wire mesh media excels in high particulate environments, offering robust filtration without rapid blinding. This extends service life and maintains flow rates even when dust and debris are prevalent.
Continuous-Duty Hydraulic Systems
For machinery running around the clock, consistent 25 µm protection prevents wear in pumps and valves. The reliable particle capture reduces unscheduled downtime and component repair costs.
Streamlined Fleet Maintenance
Using a single aftermarket filter across multiple Hydac-equipped machines simplifies inventory. Bulk ordering becomes feasible, lowering per-unit costs and reducing administrative overhead.
Scheduled Preventive Maintenance
The drop-in design allows quick filter swaps during routine service intervals. Maintenance crews can replace elements faster, minimising labour time and keeping equipment operational.
This filter is a direct replacement for Hydac hydraulic filter elements that match these dimensions. Verify your existing filter's height (157 mm), inner diameter (22.1 mm), and outer diameter (44.5 mm). If they align and your system uses an out-to-in flow direction, this filter will fit correctly.
The filter uses wire mesh media with an absolute rating of 25 µm. This means it removes 99.9% of particles 25 micrometres and larger, providing reliable protection for hydraulic components.
The filter element has a total height of 157 mm, largest inner diameter of 22.1 mm, and largest outer diameter of 44.5 mm. It does not include a threaded centre post and seals via the inner and outer diameters inside a standard filter housing.
No, this filter is an aftermarket part manufactured to match the performance and dimensions of the original Hydac filter. It is not affiliated with Hydac but is built as a direct, cost-effective replacement.
Ensure the hydraulic system is depressurised and the fluid is cool. Remove the filter housing, take out the old element, and inspect the housing for debris. Lubricate the new filter's seals with clean hydraulic fluid, slide it into place, and reassemble the housing. Run the system briefly and check for leaks.
Spare Part Mart provides worldwide shipping with tracking. Every order is covered by a 30-day money-back guarantee and our price-beat guarantee. If you find a lower price elsewhere, we will beat it.
