| Part Type | High pressure filter element |
| Replaces | Hy-Pro HP51L82MV / Pall HC9651FDP8Z |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 3 µm, beta 1000 (ISO 16889) |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton) |
| Largest Outer Diameter | 78.5 mm (3 3/32") |
| Largest Inner Diameter | 42.6 mm (1 11/16") |
| Total Height | 206 mm (8 1/8") |
| Collapse Rating | 210 bar (3,045 psid), high collapse |
| Construction | Double open end |
| Nominal Length | 8 in |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Hy-Pro | HP51L82MV |
| Pall | HC9651FDP8Z |
| Spare Part Mart | SPM-HYD-2603 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| SONA Filtration | USD 125.61 | 5 Oct 2026 |
| MicroFit | USD 261.00 | 5 Oct 2026 |
| Filtrec | USD 293.00 | 5 Oct 2026 |
| Spare Part Mart | USD 100.49 | Today |
Our price of USD 100.49 is 20% to 66% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Industrial power units
Hy-Pro and Pall elements sit on the power units of presses, machine tools, plastics machines and test rigs. A fresh element keeps valves and pumps at the cleanliness they were designed for.
Turbine and lube oil systems
The same element sizes run on turbine lube and control oil skids, gearbox lubrication and compressor lube systems, where clean oil decides bearing life.
Steel, paper and energy plants
Mill and power plant hydraulic systems use these elements in duplex filters, so the change can happen on line as soon as the indicator trips.
Planned maintenance stock
Sites with several filters on the same element can hold stock for scheduled changes at a lower price than buying OEM every time.
No. It is an aftermarket element made to the dimensions and filtration grade of the Hy-Pro HP51L82MV / Pall HC9651FDP8Z. It is not made by or affiliated with Hy-Pro or Pall, and their part numbers are used only to show what it replaces.
Yes if your filter takes the Hy-Pro HP51L82MV or Pall HC9651FDP8Z. Check the old element: 78.5 mm outside diameter, 42.6 mm bore and 206 mm overall length.
The element has a reinforced core rated to 210 bar (3,045 psid) differential, so it will not fold if it clogs in a pressure filter that has no bypass valve.
Fluorocarbon (FKM / Viton) seals, shown by the V at the end of the Hy-Pro number and the Z at the end of the Pall number. They suit mineral oil, synthetic and most fire resistant fluids and higher oil temperatures.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
