Maintain equipment health with this Ingersoll Rand FA110 IG compatible In-line Filter. Built for high-pressure cycles.
| Bottom Cap (BC) | Interupted Flange |
| Differential Pressure | 50 mbar |
| Filtration Media (FILT-MED) | Borosilicate micro glass fibre 0.1 µm 3 |
| Media type (MED-TYPE) | Borosilicate micro glass fibre |
| Filtration Rating (F-RATE) | 0.1 µm |
| Solids Q Class | 3 |
| Body Height (H-0) | 118 mm |
| Height-1 (H-1) | 7 mm |
| Total Height (H-TOTAL) | 125 mm |
| Maximum Working Temperature | 65 °C |
| Minimum Working temperature | 1.5 °C |
| Top Cap (TC) | Male single O-ring Flange |
| Outer Diameter (Ø OUT) | 55 mm |
| Largest Outer Diameter (Ø OUT-MAX) | 65 mm |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| HiFi Filter | SI 35031 |
| Ingersoll Rand | 24241952 |
| Ingersoll Rand | FA110 IG |
| Ingersoll Rand | FA110IG |
| Noitech | NM 001541 |
| Omega Air | 1010100106114 |
| Omega Air | OIR FA110 IG/XM |
| Oxfil | IF.3162 |
| Spare Part Mart | SPM-INF-1301 |
