Looking for a high-quality Mark 2200640625 replacement? This aftermarket Separator is precision-engineered to meet original standards.
| Element | Collapse pressure (COL-P) |
| Filtration Media (FILT-MED) | Borosilicate micro glass fibre 3 µm |
| Media type (MED-TYPE) | Borosilicate micro glass fibre |
| Filtration Rating (F-RATE) | 3 µm |
| Flow direction (FLOW-DIR) | Out-In |
| Flange (Flange) | 12 13.5 mm 215 mm 165 mm 260 mm |
| Holes | 12 |
| Hole diameter (HOLE Ø) | 13.5 mm |
| Pitch Circle Diameter (PCD) | 215 mm |
| Inner Diameter (ID) | 165 mm |
| Outer diameter (OD) | 260 mm |
| Gasket (GASK) | 12 13.5 mm 215 mm 180 mm 260 mm Organic fiber bonded NBR / SBR 2 |
| Holes | 12 |
| Hole diameter (HOLE Ø) | 13.5 mm |
| Pitch Circle Diameter (PCD) | 215 mm |
| Inner Diameter (ID) | 180 mm |
| Outer diameter (OD) | 260 mm |
| Material (S-MAT) | Organic fiber bonded NBR / SBR |
| Pieces (PCS) | 2 |
| Body Height (H-0) | 305 mm |
| Total Height (H-TOTAL) | 305 mm |
| Product Net Weight (WEIGHT) | 3.3 Kg |
| Largest Inner Diameter (Ø IN-MAX) | 110 mm |
| Smallest Inner Diameter (Ø IN-MIN) | 108 mm |
| Outer Diameter (Ø OUT) | 168 mm |
| Largest Outer Diameter (Ø OUT-MAX) | 260 mm |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Alup | 6221374450 |
| Atlas Copco | 6221374400 |
| Ceccato | 2200640584 |
| Ceccato | 2200640625 |
| Ceccato | 6221374400 |
| Ceccato | 6221374450 |
| Ceccato | 640584 |
| Chicago Pneumatic | 2902021980 |
| Chicago Pneumatic | 6221374450 |
| Fai Filtri | DFF-170305-06 |
| HiFi Filter | OT 2081 |
| Mark | 2200640584 |
| Mark | 2200640625 |
| Mark | 6221374450 |
| Mark | 640584 |
| Noitech | NS 019430 |
| Oxfil | SP.3188 |
| SF Filter | SAO59004 |
| Sotras | DC 3188 |
| Sotras | DC3188 |
| Sotras | DC3194 |
| Spare Part Mart | SPM-SEP-1101 |
| T.G. Filter | 3170300 C |
| T.G. Filter | 3170300C |
