| Collapse pressure | 21 bar (305 PSI) |
| Filtration Media | Inorganic Microfibers 25 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 25 µm |
| Flow direction | Out-In |
| Height-1 | 9 mm (11/32") |
| Total Height | 135 mm (5 5/16") |
| Largest Inner Diameter | 36 mm (1 13/32") |
| Largest Outer Diameter | 60 mm (2 3/8") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Airfil | AFKOVL31120 |
| Fai Filtri | CF-22-P-1-A25-NA |
| Hy-Pro | HP170L525MB |
| Oxfil | HF.7604 |
| Pall | HC2256FKT6H |
| Parker Parfit | GO1930Q |
| Parker Parfit | GO4397Q |
| Spare Part Mart | SPM-HYD-1269 |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
High-Pressure Hydraulic Systems
In systems operating near 21 bar, this filter's robust collapse pressure rating ensures it maintains integrity under stress, protecting downstream components from contamination and preventing costly failures.
Continuous-Duty Industrial Machinery
For equipment running extended cycles, the 25 µm inorganic microfiber media provides consistent filtration efficiency, reducing wear on pumps and valves and extending maintenance intervals.
Mobile Hydraulic Equipment
On construction or agricultural machinery exposed to dust and debris, the out-in flow design effectively traps particles before they can circulate, safeguarding hydraulic circuits in harsh environments.
Inventory Consolidation Across Brands
With cross-reference compatibility to multiple brands, this single filter can replace units from Airfil, Fai Filtri, Hy-Pro, Oxfil, Pall, and Parker Parfit, simplifying stock management for workshops servicing diverse equipment.
Check your existing filter's dimensions: total height 135 mm, largest outer diameter 60 mm, largest inner diameter 36 mm. Also verify flow direction is out-in. If these match, this filter is a direct replacement.
This filter uses inorganic microfibers with a 25 µm filtration rating, suitable for removing fine particles from hydraulic fluids while maintaining flow efficiency.
The filter has an outer diameter of 60 mm, inner diameter of 36 mm, and total height of 135 mm. The height-1 dimension is 9 mm. Thread details are not specified; refer to your housing for compatibility.
No, this is an aftermarket replacement built to match OEM specifications for brands like Airfil, Fai Filtri, Hy-Pro, Oxfil, Pall, and Parker Parfit. It offers comparable performance at a competitive price.
Installation is straightforward: remove the old filter, ensure the housing is clean, lubricate the gasket, and screw in the new filter hand-tight. Do not use tools. Always follow your equipment's manual.
We offer worldwide shipping with tracking. Your purchase is backed by a 30-day money-back guarantee and a price-beat guarantee. Contact us for specific delivery times.
