| Part Type | Coreless hydraulic and lube oil filter element |
| Replaces | Pall HC8314FKN26H |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 7 µm(c), Pall N grade |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR), Pall H seal code |
| Largest Outer Diameter | 152 mm (5 31/32") |
| Largest Inner Diameter | 96 mm (3 25/32") |
| Total Height | 596 mm (23 7/16") |
| Construction | Coreless, single open end |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Pall | HC8314FKN26H |
| Spare Part Mart | SPM-HYD-2214 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving approximately 20% on Pall HC8314FKN26H buying from SPM.
This element replaces Pall HC8314FKN26H, a coreless element with nitrile (H) seals, for standard mineral hydraulic oils. Coreless means the support core stays in the housing, so the element only fits Pall's coreless housings:
To check, match the length code in the old element number (26 here) and the seal letter. The length code is Pall's code, not the length in inches.
Steel mill and rolling mill hydraulics
The HC8314 is a large coreless return and off-line element used on rolling mill, coiler and descaler hydraulic systems, where big flows and long change intervals call for a 152 mm element.
Wind turbine gearbox lube
Gearbox lube and hydraulic stations on wind turbines use the HC8314 size in their off-line and return filters. Spare elements on site save a second climb when the indicator trips.
Power station lube and control oil
Turbine lube oil skids and boiler feed pump lube systems run HC8314 housings. Holding spares lets the change happen at the next planned outage.
Large industrial power units
Presses, injection moulding lines and test rigs with big tanks use the HC8314 for return line filtration at high flow with low pressure drop.
No. It is an aftermarket element made to the dimensions and filtration grade of the Pall HC8314FKN26H. It is not made by or affiliated with Pall, and the Pall part number is used only to show what it replaces.
Yes if your housing takes the Pall HC8314FKN26H. Check the old element: 152 mm outside diameter, 96 mm bore and 596 mm overall length. It is a coreless element, so it needs the housing's own support core.
It is the particle size the media captures at a beta ratio of 1000 or more under the ISO 16889 multipass test, so it removes at least 99.9% of particles of 7 µm and larger on each pass.
H means nitrile (NBR) seals. The Z (HC8314FKN26Z) version of the same element has fluorocarbon seals; make sure you order the seal material your fluid needs.
Change it when the housing's differential pressure indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first. A loaded element that goes into bypass lets dirty oil through.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
