| Part Type | Coreless filter element |
| Replaces | Schroeder 13QCLZ10V / Pall HC8314FKS13Z |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 10 µm, beta 1000 (ISO 16889) |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton) |
| Largest Outer Diameter | 152 mm (5 31/32") |
| Largest Inner Diameter | 96 mm (3 25/32") |
| Total Height | 273 mm (10 3/4") |
| Construction | Coreless (the core stays in the filter housing), plastic end caps with lifting handle |
| Collapse Rating | 10 bar (150 psid) |
| Nominal Length | 13 in |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Pall | HC8314FKS13Z |
| Schroeder | 13QCLZ10V |
| Spare Part Mart | SPM-HYD-2591 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-85% on Pall HC8314FKS13Z buying from SPM.
Turbine and compressor lube oil
Coreless 8314 size elements are common on turbine lube oil skids and large compressor lube systems, where long element life matters.
Return and kidney loop filters
The large diameter gives a high dirt holding capacity on return lines and offline kidney loop filters of big power units.
Steel, paper and energy plants
Rolling mill, paper machine and power plant hydraulic systems run these elements in duplex housings, so a spare lets one side be changed on line.
Lower disposal cost
With no metal core in the element, used elements are lighter and cheaper to dispose of than cored elements of the same size.
No. It is an aftermarket element made to the dimensions and filtration grade of the Schroeder 13QCLZ10V / Pall HC8314FKS13Z. It is not made by or affiliated with Schroeder Industries or Pall, and their part numbers are used only to show what it replaces.
Yes if your filter takes the Schroeder 13QCLZ10V / Pall HC8314FKS13Z. Check the old element: 152 mm outside diameter, 96 mm bore and 273 mm overall length.
The element has no inner support tube. The perforated core is part of the filter housing and stays in place, and the new element slides over it. Do not fit a coreless element in a housing that has no core.
They describe the same element: 13 in long, the same grade and fluorocarbon seals. Schroeder writes it as 13QCLZ10V, Pall as HC8314FKS13Z.
Fluorocarbon (FKM / Viton) seals, shown by the V at the end of the Schroeder number and the Z at the end of the Pall number. They suit mineral oil, synthetic and most fire resistant fluids.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
