| Part Type | Hydraulic filter element |
| Replaces | Pall HC9020FCZ8H |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 3 µm(c), Pall Z grade |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR), Pall H seal code |
| Largest Outer Diameter | 45 mm (1 25/32") |
| Largest Inner Diameter | 25.4 mm (1") |
| Total Height | 209 mm (8 7/32") |
| Nominal Length | 8 in |
| End Configuration | Single open end |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Pall | HC9020FCZ8H |
| Spare Part Mart | SPM-HYD-2213 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving approximately 20% on Pall HC9020FCZ8H buying from SPM.
This element replaces Pall HC9020FCZ8H, the 8 inch element with nitrile (H) seals, for standard mineral hydraulic oils. It fits the Pall high pressure filter assemblies that take 8 inch HC9020 elements:
To check, read the element number on the old element or the housing data plate: the 8 is the length code (8 inch, not the 4 inch HC9020 element) and the last letter is the seal. Order the same seal letter as the one you are replacing.
Servo and proportional valve protection
Fine filtration ahead of servo and proportional valves keeps spools from silting and sticking. The 3 µm(c) grade is the usual choice for these circuits.
Injection moulding and presses
Machines with high response valves need clean oil to hold cycle times and repeatability. Changing elements on schedule protects the valves.
Mobile and industrial pilot circuits
Pilot and control oil lines on mineral oil systems use the small HC9020 element. The nitrile seals suit standard hydraulic oils.
Spares for duplex housings
Duplex housings let you change one side while the other runs. Holding spare elements means the change can happen as soon as the indicator trips.
No. It is an aftermarket element made to the dimensions and filtration grade of the Pall HC9020FCZ8H. It is not made by or affiliated with Pall, and the Pall part number is used only to show what it replaces.
Yes if your housing takes the Pall HC9020FCZ8H. Check the old element: 45 mm outside diameter, 25.4 mm bore and 209 mm overall length.
It is the particle size the media captures at a beta ratio of 1000 or more under the ISO 16889 multipass test, so it removes at least 99.9% of particles of 3 µm and larger on each pass.
H means nitrile (NBR) seals. The Z (HC9020FCZ8Z) version of the same element has fluorocarbon seals; make sure you order the seal material your fluid needs.
Change it when the housing's differential pressure indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first. A loaded element that goes into bypass lets dirty oil through.
