| Part Type | Hydraulic filter element |
| Replaces | Pall HC9100FCN8Z |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 7 µm(c), Pall N grade |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton), Pall Z seal code |
| Largest Outer Diameter | 70 mm (2 3/4") |
| Largest Inner Diameter | 34 mm (1 11/32") |
| Total Height | 208 mm (8 3/16") |
| Nominal Length | 8 in |
| Construction | Single open end |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Pall | HC9100FCN8Z |
| Spare Part Mart | SPM-HYD-2232 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving approximately 20% on Pall HC9100FCN8Z buying from SPM.
Servo and proportional valve protection
Fine HC9100 elements sit ahead of servo and proportional valves, where small particles cause spool wear and drift.
Turbine control and fire resistant fluids
Fluorocarbon seals make the Z version the usual choice on phosphate ester control oil systems and hot oil circuits.
Machine tools and presses
Clamping, spindle and press circuits use compact HC9100 housings. Clean oil keeps cycle times and positioning repeatable.
Industrial power units
Small and medium power units fit HC9100 filters on the pressure or return line. A spare element keeps the unit running when the indicator trips.
No. It is an aftermarket element made to the dimensions and filtration grade of the Pall HC9100FCN8Z. It is not made by or affiliated with Pall, and the Pall part number is used only to show what it replaces.
Yes if your housing takes the Pall HC9100FCN8Z. Check the old element: 70 mm outside diameter, 34 mm bore and 208 mm overall length.
It is the particle size the media captures at a beta ratio of 1000 or more under the ISO 16889 multipass test, so it removes at least 99.9% of particles of 7 µm and larger on each pass.
Z means fluorocarbon (FKM / Viton) seals. The H (HC9100FCN8H) version of the same element has nitrile seals; make sure you order the seal material your fluid needs.
Change it when the housing's differential pressure indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first. A loaded element that goes into bypass lets dirty oil through.
