| Filtration Media | Inorganic Microfibers 25 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 25 µm |
| Flow direction | Out-In |
| Total Height | 248 mm (9 3/4") |
| Largest Inner Diameter | 25.5 mm (1") |
| Largest Outer Diameter | 47 mm (1 27/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Behringer | BE3011025A |
| Comex | M0011DH2025 |
| Comex | M0011DH25 |
| Fai Filtri | CF-111-A25-HA |
| Fleetguard | ST1525 |
| Hy-Pro | HP301L1025M |
| Hydac | 1269236 |
| Hydac | 2110D25BH |
| Internormen | 04PI421125VGHREO |
| Internormen | 301050 |
| Mahle | 77680523 |
| Mahle | PI4211SMXVST25 |
| Oxfil | HF.7448 |
| Parker Parfit | 935234 |
| Parker Parfit | GO2851 |
| Parker Parfit | PR2851 |
| PTI | PG035JU |
| Spare Part Mart | SPM-HYD-1189 |
| Stauff | SL030F20B |
| Woodgate | WGH9926 |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Continuous-Duty Hydraulic Systems
In applications where hydraulic equipment runs 24/7, the 25 µm inorganic microfibre media ensures consistent filtration without rapid clogging, reducing downtime for filter changes.
Cold-Start Environments
The robust media construction maintains filtration efficiency even with high-viscosity oil during cold starts, preventing contaminants from bypassing the filter.
High-Pressure Circuits
Designed for out-in flow, this filter handles high-pressure return lines effectively, protecting downstream components from wear caused by fine particles.
Fleet Maintenance Consolidation
As a cross-reference for multiple brands, this filter simplifies inventory management for workshops servicing diverse hydraulic equipment, reducing stock complexity.
Check your current filter's part number against our cross-reference list for brands like Hydac, Mahle, or Stauff. Alternatively, measure your filter's dimensions: our filter has a total height of 248 mm, outer diameter of 47 mm, and inner diameter of 25.5 mm.
This filter uses inorganic microfibre media with a 25 µm filtration rating, suitable for fine particulate removal in hydraulic systems.
We do not specify thread type; the filter has a largest inner diameter of 25.5 mm and outer diameter of 47 mm. Ensure your housing matches these dimensions.
This is an aftermarket replacement built to match OEM specifications. It is not a genuine OEM part but offers equivalent performance at a lower cost.
Installation is straightforward: remove the old filter, clean the housing, lubricate the gasket, and screw in the new filter hand-tight. Ensure flow direction is out-in as marked.
