| Part Type | Coreless return / filter element |
| Replaces | Rexroth R900987511 / Pall HC8314FKN39Z |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 5 µm, beta 1000 (ISO 16889), Pall KN grade |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton) |
| Largest Outer Diameter | 151 mm (5 15/16") |
| Largest Inner Diameter | 96.5 mm (3 13/16") |
| Total Height | 922 mm (36 5/16") |
| Construction | Coreless (the core stays in the filter housing), plastic end caps with lifting handle |
| Collapse Rating | 10 bar (150 psid) |
| Nominal Length | 39 in |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Pall | HC8314FKN39Z |
| Rexroth | R900987511 |
| Spare Part Mart | SPM-HYD-2588 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-38% on Rexroth R900987511 buying from SPM.
Turbine and compressor lube oil
Coreless 8314 size elements are common on steam and gas turbine lube oil skids and large compressor lube systems, where long element life matters.
Return and kidney loop filters
The 39 in length gives a large dirt holding capacity on return lines and offline kidney loop filters of big power units.
Steel, paper and energy plants
Rolling mill, paper machine and power plant hydraulic systems run these elements in duplex housings, so a spare lets one side be changed on line.
Lower disposal cost
With no metal core in the element, used elements are lighter and cheaper to dispose of than cored elements of the same size.
No. It is an aftermarket element made to the dimensions and filtration grade of the Rexroth R900987511 / Pall HC8314FKN39Z. It is not made by or affiliated with Rexroth or Pall, and their part numbers are used only to show what it replaces.
Yes if your filter takes the Pall HC8314FKN39Z or Rexroth R900987511. Check the old element: 151 mm outside diameter, 96.5 mm bore and 922 mm overall length.
The element has no inner support tube. The perforated core is part of the filter housing and stays in place, and the new element slides over it. Do not fit a coreless element in a housing that has no core.
In Pall's code, 8314 is the element series, KN is the 5 µm glass fibre grade, 39 is the nominal length in inches and Z is the fluorocarbon seal.
Fluorocarbon (FKM / Viton) O-ring seals. They suit mineral oil, synthetic and most fire resistant fluids and higher oil temperatures.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
