| Part Type | Hydraulic filter element |
| Replaces | Pall HC9020FCZ8Z |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 3 µm(c), Pall Z grade |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton) |
| Largest Outer Diameter | 45 mm (1 25/32") |
| Largest Inner Diameter | 25.4 mm (1") |
| Total Height | 209 mm (8 7/32") |
| Nominal Length | 8 in |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Pall | HC9020FCZ8Z |
| Spare Part Mart | SPM-HYD-2204 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving approximately 20% on Spare Part Mart SPM-HYD-2204 buying from SPM.
Servo and proportional valve protection
Fine filtration ahead of servo and proportional valves keeps spools from silting and sticking. The 3 µm(c) grade is the usual choice for these circuits.
Turbine control oil
Electro-hydraulic control systems on steam and gas turbines often run phosphate ester fluid, which needs fluorocarbon seals. This element is the fluorocarbon (Z) version.
Injection moulding and presses
Machines with high response valves need clean oil to hold cycle times and repeatability. Changing elements on schedule protects the valves.
Spares for duplex housings
Duplex housings let you change one side while the other runs. Holding spare elements means the change can happen as soon as the indicator trips.
No. It is an aftermarket element made to the dimensions and filtration grade of the Pall HC9020FCZ8Z. It is not made by or affiliated with Pall, and the Pall part number is used only to show what it replaces.
Yes if your housing takes the Pall HC9020FCZ8Z. Check the old element: 45 mm outside diameter, 25.4 mm bore and 209 mm overall length.
It is the particle size the media captures at a beta ratio of 1000 or more under the ISO 16889 multipass test, so it removes at least 99.9% of particles of 3 µm and larger on each pass.
Z means fluorocarbon seals, which suit phosphate ester fluids and higher temperatures as well as mineral oil. The H version of the same element has nitrile seals.
Change it when the differential pressure indicator shows the element is loaded, or at your maintenance interval, whichever comes first.
