| Element Collapse pressure | 10 bar (145 PSI) |
| Filtration Media | Inorganic Microfibers 14 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 14 µm |
| Flow direction | Out-In |
| Total Height | 160 mm (6 5/16") |
| Largest Inner Diameter | 52.6 mm (2 1/16") |
| Largest Outer Diameter | 100 mm (3 15/16") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Fai Filtri | CF-RN-0160-A16-NA |
| Fleetguard | ST1976 |
| Internormen | 01NR16016VG10BP |
| Mahle | PI24016RNSMX16 |
| Oxfil | HF.8428 |
| Spare Part Mart | SPM-HYD-1452 |
| Stauff | NR160E16B |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Harsh Environment Protection
Hydraulic systems operating in dusty, dirty, or high-particulate settings rely on the 14 µm microfibre media to capture fine contaminants before they circulate. This guards against accelerated wear on precision components, extending the service life of expensive equipment even under severe conditions.
Continuous Duty Reliability
For machinery that runs around the clock, the filter’s 10 bar collapse pressure rating ensures the element holds its shape and maintains filtration efficiency under sustained high flow and pressure. This minimises the risk of bypass and keeps critical systems protected without frequent shutdowns.
Streamlined Fleet Maintenance
By cross-referencing multiple brands, this single cartridge simplifies inventory management for workshops servicing mixed machinery. Instead of stocking several different part numbers, one this filter can cover routine filter changes across a range of equipment, saving shelf space and procurement time.
Check your existing filter’s dimensions against those of this filter: total height 160 mm, largest outer diameter 100 mm, and largest inner diameter 52.6 mm. It directly replaces cartridge elements from Fai Filtri, Fleetguard-ST, Internormen, Mahle, Oxfil, and Stauff, so matching part numbers from those brands confirms compatibility.
The inorganic microfibre media is rated at 14 µm, meaning it removes solid particles 14 micrometres and larger from the hydraulic fluid. This level of filtration is suitable for protecting sensitive proportional valves and high-pressure pumps in industrial and mobile hydraulic systems.
The cartridge stands 160 mm tall, with a largest inner diameter of 52.6 mm and largest outer diameter of 100 mm. Fluid flows from the outside to the inside (Out-In), which is typical for many return-line and inline filter housings. No threaded connections are used, as the element seats between end caps in the filter bowl.
It is an aftermarket replacement built to match OEM specifications. It is not branded by the original equipment manufacturers, but it delivers dependable filtration at a more accessible price point. Our 30-day money-back guarantee gives you time to verify fit and performance.
Shut down the hydraulic system and relieve pressure according to manufacturer guidelines. Drain the filter housing, remove the old cartridge, and insert the new this filter, ensuring correct orientation. Reassemble the housing, refill or reinitiate the system, and check for leaks. Special tools are not required.
