| Part Type | Line filter element |
| Replaces | Taisei Kogyo P-UL-10A-20U |
| Filtration Media | Pleated filter paper |
| Filtration Rating | 20 µm, Taisei 20U paper grade |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR) |
| Largest Outer Diameter | 83.5 mm (3 9/32") |
| Largest Inner Diameter | 45.7 mm (1 13/16") |
| Total Height | 204 mm (8 1/32") |
| Housing Size | UL-10A |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Spare Part Mart | SPM-HYD-2374 |
| Taisei Kogyo | P-UL-10A-20U |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving approximately 20% on Taisei Kogyo P-UL-10A-20U buying from SPM.
Machine tool hydraulics
Taisei Kogyo line filters are fitted to the hydraulic units of Japanese lathes, machining centres and grinders. The element keeps the valves and pump clean on machines that run every shift.
Injection moulding machines
Moulding machines from Japanese builders use Taisei UL and UM filters on the power unit. A spare element on the shelf lets the change happen at the next mould change.
Lubrication and coolant circuits
The same line filters sit on spindle lube and gearbox lubrication circuits, where a clean element protects bearings and gears.
Planned maintenance stock
Sites with several machines on the same filter size can hold elements for scheduled changes at a lower price than buying OEM every time.
No. It is an aftermarket element made to the dimensions and filtration grade of the Taisei Kogyo P-UL-10A-20U. It is not made by or affiliated with Taisei Kogyo, and the Taisei part numbers are used only to show what it replaces.
Yes if your filter takes the Taisei Kogyo P-UL-10A-20U. Check the old element: 83.5 mm outside diameter, 45.7 mm bore and 204 mm overall length.
Taisei Kogyo puts P- in front of the filter model to mean the replacement element only. The filter housing carries the same number without the P.
Taisei Kogyo grades are written as the rating in µm followed by U for filter paper or UW for wire mesh. 20U is a 20 µm pleated paper element, the usual grade for machine tool and moulding machine hydraulics.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
