| Element Collapse pressure | 5 bar (73 PSI) |
| Filtration Media | Borosilicate micro glass fibre 3 µm |
| Media type | Borosilicate micro glass fibre |
| Filtration Rating | 3 µm |
| Permissible Flow | 870 m3/h |
| Flow direction | Out-In |
| Gasket | Organic fiber bonded NBR / SBR 2 |
| Total Height | 305 mm (12") |
| Product Net Weight | 4.07 kg (8.97 lbs) |
| Largest Inner Diameter | 157 mm (6 3/16") |
| Outer Diameter | 220 mm (8 21/32") |
| Largest Outer Diameter | 272 mm (10 23/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Almig | 57210101 |
| Compair-Demag | 100005424 |
| Compair-Demag | 100013004 |
| Fai Filtri | DFN-220305-H0 |
| HiFi Filter | OS 5013 |
| Mann-Filter / Mann & Hummel | 4930253591 |
| Mann-Filter / Mann & Hummel | 4930255371 |
| Mann-Filter / Mann & Hummel | 4930255771 |
| Mann-Filter / Mann & Hummel | 4940854111 |
| Mann-Filter / Mann & Hummel | 4940854141 |
| Mann-Filter / Mann & Hummel | LE 22 009 x |
| Noitech | NS 010420 |
| Oxfil | SP.2104 |
| Pneumofore | 043314 |
| Pneumofore | 43314 |
| Pneumofore | 53314 |
| SF Filter | SAO 57470 |
| SF Filter | SAO57470 |
| Sotras | DB 2104 |
| Sotras | DB2104 |
| Spare Part Mart | SPM-SEP-1058 |
| T.G. Filter | 2220305 |
| Wittig | 43259300 |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
High-Volume Continuous Operation
In industrial plants running Compair-Demag L 75 RS or L 55 G compressors non-stop, the 870 m³/h flow capacity handles peak demand without pressure drop, maintaining system efficiency during extended shifts.
Dusty and Harsh Environments
For Gardner ESM 75 or ESM 80 compressors operating in construction or mining sites, the 3 µm borosilicate media captures fine particulates, protecting downstream equipment from abrasive wear.
Scheduled Maintenance Programs
Facilities with multiple L 55 and L 75 units can standardise on this separator, simplifying inventory management and ensuring consistent replacement intervals across the fleet.
Retrofit for Older Models
Upgrading a 2004 Compair-Demag L 55 with this aftermarket separator restores filtration performance to original specs, extending the compressor's service life without costly OEM parts.
Check your compressor's model number against the verified list: Compair-Demag L 55 RS, L 55 from 2004, L 55 G, L 75 RS, L 75 from 2004, L 75 G, Gardner VS 75, ESM 75, ESM 80, ESM 55. Also verify dimensions: total height 305 mm, largest inner diameter 157 mm, outer diameter 220 mm, largest outer diameter 272 mm.
The filter media is borosilicate micro glass fibre with a 3 µm filtration rating. This provides effective removal of oil mist and fine particles from compressed air.
Total height is 305 mm, outer diameter 220 mm, largest outer diameter 272 mm, and largest inner diameter 157 mm. The gasket is organic fiber bonded NBR/SBR. Flow direction is out-in. No thread specifications are provided.
No, this is an aftermarket replacement element built to match OEM specifications. It is not a genuine or OEM part, but a cost-effective alternative that meets the same performance parameters.
Installation is straightforward: ensure the compressor is off and depressurised. Remove the old element, clean the housing, fit the new element with the gasket in place, and secure the cover. Follow your compressor manual for specific steps.
We offer worldwide shipping with tracking. Your purchase is covered by a 30-day money-back guarantee and our price-beat guarantee.
Prices depend on your postcode.
In USD for the quantity selected. The exact cost is confirmed at checkout.
