| Part Type | Pressure filter element |
| Replaces | Internormen 01.E 90.6VG.HR.E.P (article 300117) |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 6 µm(c), Internormen 6VG glass fibre grade |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR) |
| Largest Outer Diameter | 44.5 mm (1 3/4") |
| Largest Inner Diameter | 22.2 mm (7/8") |
| Total Height | 175 mm (6 7/8") |
| Nominal Size | 90 |
| End Configuration | Single open end |
| Collapse Rating | 160 bar (2,320 psid), Internormen HR high collapse design |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Internormen | 01.E90.6VG.HR.E.P |
| Internormen | 300117 |
| Spare Part Mart | SPM-HYD-2272 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| Filtration Point | USD 80.36 | 8 Oct 2026 |
| eBay, aftermarket seller | USD 87.08 | 8 Oct 2026 |
| Cardinal Filters | USD 106.06 | 8 Oct 2026 |
| Hydrafil | USD 216.95 | 8 Oct 2026 |
| Spare Part Mart | USD 64.29 | Today |
Our price of USD 64.29 is 20% to 70% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
High pressure inline filters
Size 90 01.E elements sit in compact high pressure filters on the pump outlet or ahead of a single valve. The HR element holds 160 bar differential, so it is used where the filter has no bypass.
Servo and proportional valves
The 6VG grade protects servo and proportional valves, where fine silt causes spool sticking and drift.
Coal mill and power station hydraulics
Mill loading cylinders, damper drives and turbine control circuits use small Internormen pressure filters. Spares on the shelf let the change happen as soon as the indicator trips.
Machine tools and test rigs
Clamping circuits, test benches and compact power units use the size 90 filter where space is tight.
No. It is an aftermarket element made to the dimensions and filtration grade of the Internormen 01.E 90.6VG.HR.E.P (article 300117). It is not made by or affiliated with Internormen or Eaton, and their part numbers are used only to show what it replaces.
Yes if your filter takes the Internormen 01.E 90.6VG.HR.E.P (article 300117). Check the old element: 44.5 mm outside diameter, 22.2 mm bore and 175 mm overall length.
VG is Internormen's glass fibre media and 6 is the grade: it captures particles of 6 µm(c) at a beta ratio of 1000 under the ISO 16889 multipass test. HR is the high collapse design rated to 160 bar differential, for filters without a bypass valve.
E is the element design and P the nitrile (NBR) seals. The same element with V at the end has fluorocarbon (Viton) seals for fire resistant and high temperature fluids.
Change it when the filter's differential pressure indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
