Nitrile (NBR) O-Ring Assortment Kit, Metric, ...: Kaeser E22KD is the replacement KD grade particulate element for the Kaeser F22KD in-line compressed air filter, which catches dry dust and desiccant fines after an adsorption dryer. It is used on Kaeser F22 series in-line compressed air filters. This aftermarket version is made to the same mounting and connections as the original, so it fits where the old one came off.
The same part is also sold as Kaeser 901543.0.
Sold as one unit. Check the number on your old part, or in the parts manual for your machine, before ordering.
| Part Type | Particulate Line Filter Element |
| Replaces | Kaeser E22KD |
| Filter grade | KD, particulate (dry dust) |
| Removes | Dry dust and solid particles |
| Oil rating | Not an oil filter: for dry air only |
| Position in the line | After a desiccant (adsorption) dryer, to catch desiccant dust |
| Housing | Kaeser F22 in-line filter, rated 2.2 m³/min (78 cfm) at 7 bar (KB, KE, KD and KA elements share the housing size) |
| Supplied as | Single element with O ring |
| Cross references | Kaeser 901543.0 |
| Fits | Kaeser F22KD |
| Condition | New, aftermarket |
| Outer Diameter | 61 mm (2 13/32"), 84 mm (3 5/16") over the end cap |
| Height | 191 mm (7 17/32") |
| Stat. HS-Code | 842199 |
| Country of Manufacture | China |
Kaeser machines
Check the part number on your old unit before ordering.
| Kaeser Part No.(SPM Part No.) | Fits |
|---|---|
| E22KD / 901543.0(SPM-ACP-3643) | Kaeser F22KD |
| Brand | Part No. |
|---|---|
| Kaeser | E22KD (this page, SPM-ACP-3643) |
| Kaeser | 901543.0 |
All of these numbers are the same part.
After a desiccant dryer
Desiccant beads wear and shed fine dust. A KD element after the dryer stops it reaching valves, cylinders and instruments.
Rising pressure drop
Particulate elements load up with dust over time. Change it when the differential pressure gauge reaches the red zone or once a year.
Dry air only
A KD element is not made to coalesce oil or water. Fit a KB or KE element where liquid is present.
Fitting tips
Isolate and vent the housing, fit the new element with its O ring and check the seal before repressurising.
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| eBay (3 aftermarket sellers) | USD 136.16 to 293.36 | 25 Oct 2026 |
| The Air Market | USD 245.86 | 20 Oct 2026 |
| Compressor Now | USD 282.00 | 20 Oct 2026 |
| Air Compressor Services | USD 386.50 | 20 Oct 2026 |
| Spare Part Mart | USD 108.93 | Today |
Our price of USD 108.93 is 20% to 72% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
No. It is an aftermarket part made to fit in place of Kaeser E22KD. It is not made by or affiliated with Kaeser; the Kaeser part number is used only to show what it replaces.
It fits Kaeser F22KD. Machines change parts between serial number ranges, so check the number on your old part or in your parts manual.
It is made to the same mounting and connections as the original part. Fit new gaskets and seals where they are used, and check for leaks and correct operation before putting the machine back to work.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
