Copper Sealing Washer Assortment Kit, M5 to M...: | Burst Pressure | 21 bar (305 PSI) |
| Element Collapse pressure | 5 bar (73 PSI) |
| Filtration Media | Impregnated Paper 25 µm |
| Media type | Impregnated Paper |
| Filtration Rating | 25 µm |
| Total Height | 211 mm (8 5/16") |
| Thread | UNF 1.1/4 inch Female Bottom 12 |
| Type | UNF |
| Thread Size | 1.1/4 inch |
| Orientation | Female |
| Position | Bottom |
| Product Net Weight | 0.68 kg (1.5 lbs) |
| Working Pressure | 12 bar (174 PSI) |
| Outer Diameter | 95.5 mm (3 3/4") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Ac Delco | PF1120 |
| Air Supply Co | (ASC) 010037 |
| Alco | SP1221 |
| Apureda | AO0997 |
| Atlas Copco | 2255300218 |
| Baldwin | B378 |
| Baldwin | B37810 |
| Cap | CAP310570 |
| Cim-Tek | 70112 |
| Cim-Tek | 70551 |
| Compair-Demag | 431041 |
| Compair-Demag | 436371 |
| Compair-Demag | 438371 |
| Compair-Demag | 43880 |
| Coopers | HSM6046 |
| Donaldson | P162049 |
| Donaldson | P164251 |
| Donaldson | P164352 |
| Donaldson | P167197 |
| Donaldson | P169083 |
| Fai Filtri | CS-070-5-0-P25-A |
| Fleetguard | HF6269 |
| Fram | P6321 |
| Gardner Denver | 2109412 |
| Gardner Denver | 2109640 |
| Gardner Denver | 2109648 |
| Gardner Denver | 2116510 |
| Gardner Denver | 26C32 |
| Grove | 7437000134 |
| Grove | 9304100081 |
| Hastings | LF355 |
| HiFi Filter | SH 56319 |
| Hydac | MFE811252 |
| Imer | 007 |
| Ingersoll Rand | 35296920 |
| Ingersoll Rand | 39125828 |
| Ingersoll Rand | 39138433 |
| Ingersoll Rand | 39726328 |
| Joy | 12283370013 |
| Keltec | KL1100016 |
| Keltec | KL750017 |
| Keltec | KL750020 |
| Leroi | 43.1041 |
| Leroi | 43.880 |
| Luberfiner | LFH4933 |
| Mann-Filter / Mann & Hummel | 6750259135 |
| Mann-Filter / Mann & Hummel | WD 10 010 |
| Mixjet | 19061041 |
| Noitech | NO 017680 |
| Noitech | NO 019180 |
| Oxfil | OF.9032 |
| P&H Harnischfeger | 46Z420 |
| Purolator | H40280 |
| Quincy | 123221050 |
| Quincy | 124331050 |
| Quincy | 124331052 |
| Sotras | SH 8176 |
| Sotras | SH 8191 |
| Sotras | SH8176 |
| Sotras | SH8191 |
| Spare Part Mart | SPM-OIL-1017 |
| Sullair | 2250154506 |
| Sullivan - Palatek | 19005200001 |
| WIX | 51826 |
| Woodgate | WGH6269 |
| Zinga | DE10L |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| Oxfil | USD 20.17 | 16 Oct 2026 |
| FilterFinder Online | USD 22.00 | 13 Oct 2026 |
| G&T Engine Parts | USD 23.76 | 13 Oct 2026 |
| The Air Market | USD 27.91 | 13 Oct 2026 |
| Air Compressor Services | USD 43.50 | 13 Oct 2026 |
| Compressor Parts Express | USD 115.00 | 13 Oct 2026 |
| Spare Part Mart | USD 16.14 | Today |
Our price of USD 16.14 is 20% to 86% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Continuous-Duty Industrial Compressors
For compressors running 24/7 in manufacturing plants, this filter's 25 µm media ensures consistent oil cleanliness, reducing wear on bearings and rotors. Its 12 bar working pressure handles sustained high-load operation without bypass.
Dusty Construction Environments
On job sites with airborne debris, the impregnated paper media traps fine particles that would otherwise accelerate engine wear. The filter's 21 bar burst pressure provides a safety margin against pressure spikes from clogging.
Fleet Maintenance Consolidation
Workshop managers servicing mixed fleets of Ingersoll Rand compressors (e.g., P 90, P 110, SSR 1000) can standardise on this single filter, simplifying inventory. It also fits equipment from Atlas Copco and Gardner Denver, reducing stock complexity.
High-Temperature Oil Systems
In compressors operating near thermal limits, the filter's media resists degradation from hot oil, maintaining filtration efficiency. The 5 bar collapse pressure ensures the element stays intact even if bypass valves open.
Check your compressor's serial number against the verified list: for example, the P 90 fits from s/n 210674, while the P 110 fits from s/n 313205. If your model isn't listed, contact us with your compressor's details.
The filter uses impregnated paper media with a nominal rating of 25 µm. This is suitable for standard industrial compressor oils, capturing most wear-causing particles while allowing adequate oil flow.
It has a UNF 1.1/4 inch female thread located at the bottom. The total height is 211 mm and the outer diameter is 95.5 mm. Always verify these dimensions against your existing filter.
This is an aftermarket filter built to the original dimensions and ratings. It is a direct replacement for brands like Donaldson, Fleetguard, and Fram, but it is not a genuine OEM part.
Installation is standard: lubricate the gasket with clean oil, screw on hand-tight until the gasket contacts the base, then tighten an additional 3/4 turn. Do not use a filter wrench to over-tighten.
