Sullair 02250193-574 Aftermarket Coalescing Line Filter Element

Sullair 02250193-574 is the replacement general purpose coalescing element for the FXF-1350 in-line compressed air filter, which catches particles and liquid water and oil after the compressor. It is used on Sullair FXF-1350 in-line compressed air filter housings. This aftermarket version is made to the same mounting and connections as the original, so it fits where the old one came off.

Sold as one unit. Check the number on your old part, or in the parts manual for your machine, before ordering.

Technical properties & sizes

Applications & use cases

High pressure drop across the filter
As the element loads with dirt and oil, the pressure drop rises and the compressor works harder for the same pressure at the tools. Change the element when the differential gauge reaches the red zone.

Oil or water reaching the tools
A saturated or damaged coalescing element lets liquid through to the downstream filters and the point of use. Replace it and check the drain is working.

Scheduled replacement
Coalescing elements are normally changed every 12 months or 8,000 hours, whichever comes first, even if the pressure drop still looks acceptable.

Fitting tips
Isolate and vent the housing, check the auto drain is clear, fit the new element with a clean O ring, and check the bowl seals before pressurising.

Price beat guarantee

We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:

Our price of USD 253.23 is 20% to 65% less than these sellers.

Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.

Frequently asked questions
