Aftermarket consumables for Raytools fiber laser cutting heads, including the BT240S, BM110, BM111, BM114 and BS series. Nozzles, protective windows, ceramic rings and lens sets, each matched to its Raytools part number.
Shop by Category
Aftermarket spare parts and consumables, cross-referenced to the original part numbers
A pack of 10 copper laser cutting nozzles made to the Raytools D32 standard: 32 mm outer diameter, 15 mm height and an M14 thread. They replace the Raytools 120GJT05xx...
A pack of 10 compact copper nozzles in the Raytools 3D format: 15 mm outer diameter, 19 mm height and an M8 x 0.75 thread. They replace Raytools 120GJT09xx single...
A pack of 10 copper E type bullet nozzles for Raytools BT210S and BT240S cutting heads, the slim D10.5 x H22 mm style held in place by a separate locking...
Ceramic nozzle holders (ceramic rings) for Raytools fiber laser cutting heads, in the five body sizes Raytools uses on its 2D and 3D heads: D32 M14, D28 M11, D21.4 M11,...
A pack of 10 copper D28 high speed laser cutting nozzles in the Raytools D28-H15-M11 format: 28 mm outer diameter, 15 mm height and an M11 x 0.75 thread, with...
High temperature seal rings for Raytools protective window drawers: the 32.2 x 24 x 3.55 mm seal for the D27.9 x 4.1 mm lower window (Raytools 11021M2110007, BT210S, BT240S, BM109,...
A pack of 10 copper D32 high speed laser cutting nozzles in the Raytools D32-H15-M14 format: 32 mm outer diameter, 15 mm height and an M14 thread, with the stepped...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0131. Size D18 x 2 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Sold...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0129. Size D20 x 3 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Sold...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0020. Size D24.9 x 1.5 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Fits...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0127. Size D26 x 3 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Sold...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0037 (also 211LCG0039). Size D27.9 x 4.1 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0068. Size D30 x 5 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Sold...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0045. Size D37 x 1.6 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Fits...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0078. Size D37 x 7 mm, 12 kW. Fused silica, anti reflection coated on both faces for 1064 nm fiber...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0125. Size D37 x 7 mm, 30 kW. Fused silica, anti reflection coated on both faces for 1064 nm fiber...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0075. Size D38 x 2 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Sold...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0009. Size D38.1 x 1.5 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Sold...
Aftermarket protective window for Raytools laser cutting heads. Replaces Raytools 211LCG0069. Size D50 x 2 mm. Fused silica, anti reflection coated on both faces for 1064 nm fiber lasers. Fits...
Aftermarket collimating lens set for Raytools laser cutting heads: one bi-convex and one meniscus lens, 28 mm diameter, 100 mm focal length. Matches Raytools lens part numbers 110255AACBHD0019, 110255AAFBHD0020. Where...
Aftermarket focusing lens set for Raytools laser cutting heads: one bi-convex and one meniscus lens, 28 mm diameter, 125 mm focal length. Matches Raytools lens part numbers 110255AACBHD0021, 110255AAFBHD0022. Where...
Aftermarket focusing lens set for Raytools laser cutting heads: one bi-convex and one meniscus lens, 28 mm diameter, 150 mm focal length. Matches Raytools lens part numbers 110255AACBHD0026, 110255AAFBHD0025. Where...
Aftermarket collimating lens set for Raytools laser cutting heads: one bi-convex and one meniscus lens, 30 mm diameter, 100 mm focal length. Matches Raytools lens part numbers 110255AAEBHE0096, 110255AACBHE0095, 110255AAFBHE0089,...
Aftermarket focusing lens set for Raytools laser cutting heads: one bi-convex and one meniscus lens, 30 mm diameter, 125 mm focal length. Matches Raytools lens part numbers 110255AAEBHE0098, 110255AACBHE0097, 110255AAFBHE0091,...
Aftermarket focusing lens set for Raytools laser cutting heads: one bi-convex and one meniscus lens, 30 mm diameter, 155 mm focal length. Matches Raytools lens part numbers 110255AAEBHE0094, 110255AACBHE0093. Where...
Aftermarket focusing lens set for Raytools laser cutting heads: one bi-convex and one meniscus lens, 37 mm diameter, 150 mm focal length. Matches Raytools lens part numbers 3250010325, 3250010324, 3250010288,...
Aftermarket focusing lens set for Raytools laser cutting heads: one bi-convex and one meniscus lens, 37 mm diameter, 200 mm focal length. Matches Raytools lens part numbers 3250010327, 3250010326, 3250010290,...
Aftermarket collimating lens assembly for Raytools BM110, BM111 cutting heads. Replaces Raytools kit 120AG0600A: lens holder with the lenses fitted, D30 mm, F100 mm, 3.3kW. Lenses in the kit: bi-convex...
Aftermarket focusing lens assembly for Raytools BM110, BM111 cutting heads. Replaces Raytools kit 120AG0700A: lens holder with the lenses fitted, D30 mm, F125 mm, 3.3kW. Lenses in the kit: bi-convex...
Aftermarket focusing lens assembly for Raytools BM110, BM111 cutting heads. Replaces Raytools kit 120AG0800A: lens holder with the lenses fitted, D30 mm, F155 mm, 3.3kW. Lenses in the kit: bi-convex...
Aftermarket focusing lens assembly for Raytools BM110, BM111 cutting heads. Replaces Raytools kit 120AG1400A: lens holder with the lenses fitted, D30 mm, F200 mm, 3.3kW. Fused silica optics, AR coated...
Aftermarket upper protective window for Raytools high power cutting heads. Replaces Raytools 211LCG0086, the 15 kW version of the D24.9 x 1.5 mm upper window. The upper window sits between...
Aftermarket collimating and focusing lens assemblies for the Raytools BS12K cutting head. Choose the one you need from the list: the collimating assembly, Raytools 120BS5800A (D37 mm, F100 mm, 12...
