Air Fuide AFFW000917 Aftermarket Separator

$44.83 USD

SKU: SPM-SEP-1108
Availability: in stock Many in stock Out of stock In-stock at manufacturer. Please add 5-10 days to shipping time
Weight: 1.03 kg (2.27 lb)

Keep a spare: buy 2 and the second one is 5% off ($42.59)

Electronic Timer Condensate Drain Valve for A...: ~~$25.02~~ $23.77 with this part

Nitrile (NBR) O-Ring Assortment Kit, Metric, ...: ~~$9.36~~ $8.90 with this part

Members earn 44 points on this order. Join today to earn 200 points off your first order.

Product Type: Separator
Barcode:

We ship worldwide

Economy and Express options at checkout

Need help?

Money back guarantee

We provide a 30 day 100% money back guarantee

Customer support

Dedicated support team ready to help

Air Fuide AFFW000917, direct aftermarket replacement. This aftermarket separator is a direct replacement for separators used in a wide range of rotary screw compressors. It features a permissible flow of 120 m³/h and measures 93 mm in outer diameter with a height of 212 mm. Designed to the original dimensions and ratings, it serves as a cost-effective alternative for brands including Abac, Alup, Ceccato, Chicago Pneumatic, and many others. The separator weighs 1.03 kg and is built to ensure reliable separation of oil and air in compressed air systems. Technical properties & cross references

Specifications

Permissible Flow	120 m3/h
Body Height	212 mm (8 11/32")
Total Height	212 mm (8 11/32")
Product Net Weight	1.03 kg (2.27 lbs)
Outer Diameter	93 mm (3 21/32")
Stat. HS-Code	84149000
Country of Manufacture	China

Compatible equipment

Abac

GENESIS 5.5 13 bar from 2011 SPINN 5.5 from 2011 MICRON 7.5 GENESIS 11 from 2011 MICRON 11 FORMULA 15 from 2011 GENESIS 5.5 from 2011 FORMULA 15 BA 77 from 2011 FORMULA 7.5 10/13 bar from 2011 FORMULA 5.5 10/13 bar from 2011 SPINN 7.5 from 2011 SPINN 11 from 2011 GENESIS 15 from 2011 MICRON 15 GENESIS 7.5 from 2011 FORMULA 11 from 2011 FORMULA 7.5 from 2011 FORMULA 5.5 from 2011 FORMULA 15 BA 69 VT 15 CMP SMART 15 (8-10-13 bar)FORMULA 11 GENESIS 15 BA 51 GENESIS 11 ZENITH 15-270 GENESIS 15 BA 69 VT 20 CMP SMART 20 (8-10-13 bar)FORMULA 15 BA 51 SPINN 11 GENESIS 15 ZENITH 15-500 ZENITH 15

Alup

SCK 9 from s/n CAI064290 SCK 6 from s/n CAI270445 SCK 10 from s/n CAI270445 ALLEGRO 11 from s/n CAI270445 ALLEGRO 14 C55 Air End from s/n CAI876886 SCK 8 from s/n CAI270445 SCK 15 from s/n CAI270445 ALLEGRO 8 C55 Air End s/n CAI876886 ALLEGRO 11 C55 Air End from s/n CAI876886 VARIO 15 SCK 15 up to s/n 259999 SCK 15 from s/n 260000 VARIO 11 SCK 22 up to s/n 259999 SCK 22 from s/n 260000 SCD 15 VARIO 16 SCK 8 from s/n F0606343 SCK 5 from s/n 271800 SCK 15 from s/n 271800 SOLO 6 SOLO 15 SCK 8 from s/n 260000 SCK 22 from s/n 280000 SCK 10 from s/n 271800 SOLO 7 SOLO 11

Ceccato

CSA 20 Inverter CSA 15 Inverter CSA 10 CSM 7.5 MAXI MSM 15 CSM 20 CSM 10 CSA 5.5 CSA 20 CSA 15 MSM 7.5 MSM 11 CSM 15 CSA 7.5

Chicago Pneumatic

CPVS D 15 (11 kw)CPN 15 CPVS D 20 (15 kw)CPN 10 CPVS D 10 (7.5 kw)

Mark

MSA 11 MSM 15 CSM 15 MSA 7.5 MSA 4 MSA 15 MSM 7.5 CSM 20 MSM 11 MSA 5.5 CSM 10 MSA 15 INVERTER MSA 11 INVERTER

PUSKA

CSA 5.5/10 PKM 15

Stenhoj

CK 15-20 CK 6-7-10

Worthington

Adicomp

VE 11 A WIND 15 VE 15 B VE 15 A WIND 11

Atlas

GX 7 up to s/n 619999 GX 11 up to s/n 619999 GN 7.2 GA 11 VSD from s/n AII 140000 GX 7 from s/n 620000 GA 7 C from s/n 145000 GX 5 from s/n 620000 GA 11 C fom s/n API 100000 GX 11 from s/n 620000 GA 7 VSD from s/n AII 140000 GX 5-11C GX 5 up to s/n 619999 GA 5 C from s/n 145000

Atmos

E 50 E 60-12 E 60 PB 80 E 40 E 70 Z E 60 M PD 5 R E 95

Balma

OASIS 15 MODULO 15/51 BRIO 11 GALAXY 15-270 MODULO 15/69 MODULO 11 GALAXY 15

Betico

ER 5P

Boge

SDF 15 SD 15 from s/n 21867 up to s/n 31486 S 15 from s/n 21867 up to s/n 31486 SD 15 from s/n 31487 S 15 from s/n 31487

Bottarini

KSA 11 GBV 10 KSA 11 KSA 15 KS 18 KSA 15 KS 22 DS 2-18 KS 9 KS 12

Chinook

ULISSE TK 15 ULISSE TK 7.5 ULISSE GK 7.5 ULISSE GK 11 MAESTRO 7.5 MAESTRO 11 ULISSE TK 5.5 ULISSE TK 11 ULISSE TKS 15 ULISSE GK 5.5 SCI 8 MAESTRO 5.5

Compair

L 04 SPRINT 015-022 CYCLONE 111 START 010 START 005 L 05 SC 20 DS-3 CYCLONE 215 START 007 L 07 L 11 RS

Dalgakiran

TIDY 20 TIDY 15 HGS 15 HGS 11

Ekomak

EKO 7.5 EKO 11 EKO 5.5

Fiac

SILVER 15 New Silver 7.5 TK 5.5 New Silver 10 CRS D 5.5 CRS 15 New Silver 15 CRS 7.5 TK 7 Old CRS 10 TK 15 New TK 10 SILVER 5.5 SILVER 10 New Silver 5.5 CRS D 7.5 CRS 20 New Silver 20 TK 7.5 CRS D 10 TKS 10 CRS 5.5 TK 15 Old AIRBLOCK 10-15 TK 10 Old SILVER 7.5

Fini

ROTAR BSC 10 cod 260LJ0050 VISION 11 ES BSC 15 R-EVO QUADRO 21 KSC 5 cod 260LK0051 BSC 15 Evolution QUADRO 15 KSC 10 cod 260LK0050 BSC 10 Evolution from 2015 BS 20 PLUS 15 ROTAR K-MAX 20 BSC 10 K-MAX 15 VS K-MID 10 STC ROTAR QUADRO 15 ROTAR BSC R-EVO 20 K-MAX 20 STC K-MAX 15 ROTAR BSC 20 Evolution K-MAX 11 ROTAR BSC 15 Evolution VISION 20 BSC 20 Evolution from 2015 ROTAR BSC 10 Evolution VISION 15 BSC 20 VISION 11 KSC 7 cod 260LK0050 BSC 15 Evolution from 2015 QUADRO 20 KSC 5 cod 260LK0050 BSC 15 BUILDAIR 1500 PLUS 16 ROTAR QUADRO 10 BSC 10 Evolution BS 15 PLUS 11 ROTAR QUADRO 20 ROTAR K-MAX 15 K-MAX 15 STC K-MAX 7.5 VS ROTAR BSC R-EVO 15 K-MAX 20 K-MAX 11 VS ROTAR BSC 20 cod 260LJ0050 VISION 20 ES BSC 20 R-EVO ROTAR BSC 15 cod 260LJ0050 VISION 15 ES BSC 20 Evolution

Gardner

KSA 11 KSA 15 ESM 11 ESM 11 TK ESM 7 ESM 7 TK

Komsan

VEK 5.5 VEK 10 VEK 15 VEK 7.5

MX 1500 ROTOR 1000

Mattei

BLADE 7 BLADE 4 BLADE 5 BLADE 11

Nuair

STAR 15

Osd

KD 103

Parise

PX-PXA 15 PVB 15 PVA 15 PV 15 PD 15 EC-06 PHK 15 PHA 15 PVB 20 PVA 20 PV 20 PD 20 EC-06 PHK 20 PHA R 15

Power System

PS 10 DV KELVIN 11 INDUSTRIAL 11 13/15 bar version PS 1015 13/15 bar version PS 1015 NEWTON 1307 KELVIN 15 GTEC 15 JUNIOR 7.5 13bar GTEC 11 JUNIOR 15 DV PS 9 DV JUNIOR 15 13bar PS 407 JUNIOR 11 13bar PS 1315 DV TRINITY 15 13/15 bar version TRINITY 15 INDUSTRIAL 11 PS 1309 DV EDISON DV 1309 PS 1315 13 bar version PS 1315 NEWTON 1315 PS 1005 13/15 bar INDUSTRIAL 15 13/15 bar version PS 1307 13 bar version PS 1307 PASCAL 15 NEWTON 1311 PS 1011 13/15 bar version PS 1011 GTEC 15 13/15 bar version JUNIOR 7.5 GTEC 11 13/15 bar version JUNIOR 5.5 13bar DARWIN 15 JUNIOR 15 PS 411 JUNIOR 11 PS 1315 PM PASCAL 7.5 INDUSTRIAL 15 PS 1309 PM TRINITY 11 EDISON DV 1315 TRINITY 11 13/15 bar version PASCAL 11 PS 1007 13/15 bar DARWIN 11 PS 1311 13 bar version PS 1311

Rotair

EN 15 9.5 bar

Rotorcomp

EVO6-NK-G

Shamal

ULISSE GK 11 MAESTRO 7.5 MAESTRO 11 ULISSE TKS 15 ULISSE TK 5.5 ULISSE TK 11 ULISSE GK 5.5SCI 8MAESTRO 5.5 ULISSE TK 7.5 ULISSE TK 15 ULISSE GK 7.5

Sullair

TREK 4 TREK 5.5 TREK 2.2

Termomeccanica

SCI 8

Almig

BELT 11-15 COMBI 11 FLEX 6-7-11-15 BELT 4-5-7 from serial n° F0500001 to F0606340 COMBI 15 BELT 4-5-7-10 from serial n° S0016862

Ingersoll

R 5-11UNI 7-10NIRVANA IRN7KNIRVANA IRN11KSSR UP 6-5SSR UP 6-10SSR UP 5-5SSR UP 5-11 CUNI 11-10UNI 18-8NIRVANA IRN5KSSR UP 6-7.5SSR UP 6-15 CSSR UP 5-7.5SSR UP 5-4

Renner

RS 4.0RSF 11RS TOP 11.0 - 15.0RS 1-11RSF 15RS TOP 3.0 - 4.0 - 5.5 - 7.5 - 9.0 RS 3.0 - 4.0 - 5.5 - 7.5 - 9.0RS 11.0 - 15.0

Cross references

Brand	Code
Abac	6221372850
Air Fuide	AFFW000917
Alup	6221372850
Ceccato	2200640593
Ceccato	220093001
Ceccato	6221372800
Ceccato	6221372850
Ceccato	640593
Ceccato	640593NEW
Chicago Pneumatic	6221372850
Fai Filtri	DSP-070-K1
HiFi Filter	OV 6011
Keltec	KD615008
Mann-Filter / Mann & Hummel	LB 962/6
Mann-Filter / Mann & Hummel	LB96222
Mann-Filter / Mann & Hummel	LB9626
Mark	2200640593
Mark	6221372850
Mark	640593
Noitech	NS 002150
Noitech	NS002150
Oxfil	SP.5019
PUSKA	6221372850
Quincy	22000640593
SF Filter	SPA50021
Sotras	DF 5019
Sotras	DF5019
Sotras	DF5021
Spare Part Mart	SPM-SEP-1108
Stenhoj	213137
Stenhoj	213157
T.G. Filter	96211
Worthington Creyssensac	2200640593
Worthington Creyssensac	2200640595
Worthington Creyssensac	22006540595
Worthington Creyssensac	6221372800
Worthington Creyssensac	6221372850

Price beat guarantee

We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:

Seller	Price	Checked
Oxfil	USD 56.04	16 Oct 2026
The Air Market	USD 83.70	15 Oct 2026
FilterFinder Online	USD 107.00	15 Oct 2026
Air Compressor Services	USD 184.00	15 Oct 2026
Compressor Parts Express	USD 190.56	15 Oct 2026
Spare Part Mart	USD 44.83	Today

Our price of USD 44.83 is 20% to 76% less than these sellers.

Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.

Use cases & applications

High-Volume Continuous Duty
In facilities running compressors continuously at full load, such as manufacturing plants, the 120 m³/h flow capacity ensures efficient oil separation without restricting air output, reducing the risk of oil carryover and maintaining air quality.

Multi-Compressor Consolidation
For workshops with multiple compressor brands like Abac, Alup, and Ceccato, this single separator part number simplifies inventory management. It fits many models across these brands, allowing you to stock one part for several machines.

Harsh Environment Operation
In dusty or humid environments, the robust construction of this aftermarket separator helps maintain consistent separation efficiency, extending the life of downstream filters and equipment by preventing oil mist contamination.

Scheduled Maintenance Replacement
During planned compressor servicing, swapping the separator with this direct replacement restores performance quickly. Its precise dimensions ensure a proper seal and fit, minimizing downtime and avoiding the need for modifications.

Frequently asked questions

How can I confirm this separator fits my specific compressor model?

Check your compressor's brand and model against the extensive list of verified machines provided. If your model is listed, it is a confirmed fit. For unlisted models, compare the outer diameter (93 mm), height (212 mm), and flow rating (120 m³/h) with your original part.

What is the filtration rating of this separator?

The separator is designed for oil-air separation in rotary screw compressors. While specific micron ratings are not provided, it is built to the original dimensions and ratings for efficient separation at a flow rate of 120 m³/h.

What are the exact dimensions and how do I ensure proper fit?

The outer diameter is 93 mm and the total height is 212 mm. The body height is also 212 mm. Ensure your compressor's housing accommodates these dimensions and that the flow requirement does not exceed 120 m³/h.

Is this separator an OEM part or aftermarket?

This is an aftermarket replacement, not a genuine OEM part. It is built to the original dimensions and ratings and serves as a direct replacement for the original separator in many compressor brands.

How do I install this separator?

Installation is similar to the original separator. Remove the old unit, clean the housing, and insert the new separator ensuring a proper seal. Refer to your compressor's manual for specific steps. No special tools are required.

What delivery and guarantee options are available?

We offer worldwide shipping with tracking. Your purchase is covered by a 30-day money-back guarantee and our price-beat guarantee, ensuring you get the best value.

30-day money back guarantee Worldwide delivery Price beat guarantee

Images and data are used as a guide and are deemed reliable to Spare Part Mart. Product may appear differently (e.g. colour) but will be as per the specs above. All cross references are deemed reliable to our knowledge. We encourage you to double check before ordering.
