Universal Filter Strap Wrench for Oil, Fuel a...: | Element Collapse pressure | 1 bar (15 PSI) |
| Filtration Media | Wire Mesh 90 µm |
| Media type | Wire Mesh |
| Filtration Rating | 90 µm |
| Flow direction | Out-In |
| Total Height | 146 mm (5 3/4") |
| Thread | GAS 1 inch Female |
| Type | GAS |
| Thread Size | 1 inch |
| Orientation | Female |
| Largest Inner Diameter | 42 mm (1 21/32") |
| Largest Outer Diameter | 70 mm (2 3/4") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Amlift | CPHY0015 |
| Atos | FEI100125 |
| Atos | XFUI100 |
| Bomag | 331048036 |
| Combilift | CPHY001500 |
| Domange | CB4M100 |
| Donaldson | FIOA90 |
| Donaldson | P171877 |
| Duplomatic | FSITB0100M90S101 |
| Fai Filtri | SE-050-M90-SG |
| Fleetguard | ST1381 |
| Heli | H24C750201 |
| Ikron | HF41020122ASMI125GFA01 |
| Ikron | HF41020122ASMS090GFA01 |
| Ikron | HHB10059 |
| Ikron | HHB10102 |
| John Deere | AN207571 |
| Kubota | 6874162210 |
| Kubota | 6874162211 |
| Leyland | AAU60006 |
| Manitou | 197926 |
| Manitou | 19910 |
| Manitou | 561999 |
| Oxfil | HF.9560 |
| Sofima (UFI) | 665040 |
| Sofima (UFI) | ESA22B08WMF |
| Sofima (UFI) | FAM13MNB50 |
| Spare Part Mart | SPM-HYD-1899 |
| Vandel | 4272992V01 |
| Zinga | SS100G00 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| Oxfil | USD 15.69 | 16 Oct 2026 |
| FilterFinder Online | USD 31.00 | 13 Oct 2026 |
| eBay (7 aftermarket sellers) | USD 35.57 to 39.51 | 13 Oct 2026 |
| SONA Filtration | USD 65.00 | 13 Oct 2026 |
| Spare Part Mart | USD 12.55 | Today |
Our price of USD 12.55 is 20% to 81% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Dusty construction environments
On busy building sites, airborne dust and debris constantly challenge hydraulic systems. The 90-micron wire mesh media traps coarse contaminants effectively, preventing pump wear and valve sticking while maintaining full flow even when dirt loads are high.
Continuous agricultural operations
When tractors and harvesters run for long hours in the field, any unplanned downtime erodes productivity. This filter’s robust construction and reliable wire mesh element keep hydraulic fluid clean, helping you stay on schedule through peak seasons.
Fleet inventory consolidation
Managing mixed fleets with equipment from multiple manufacturers can create a complex spare parts list. Because this single filter cross-references to many OEM and aftermarket part numbers, you can reduce inventory variety and free up shelf space.
High-flow hydraulic circuits
Systems with rapid cylinder cycling or large motor flows need a filter that imposes minimal pressure drop. With its wire mesh design and out-in flow path, this element supports efficient oil circulation while guarding sensitive components against harmful particles.
Compare your existing filter's part number with our cross-reference list for this filter, which replaces many OEM and branded elements. It is compatible with hydraulic systems in equipment from Bomag, John Deere, Kubota, and Manitou. If you do not have a part number, measure your housing to match the dimensions provided.
The filter uses a wire mesh media with a nominal rating of 90 microns. This is suited for protecting pumps, motors, and valves from larger particulate contamination commonly found in industrial and mobile hydraulic systems.
The connection is a GAS 1-inch female thread. Overall height is 146 mm, the largest outer diameter is 70 mm, and the largest inner diameter is 42 mm. Always verify these measurements against your filter housing to ensure a correct fit.
It is an aftermarket direct replacement, not a genuine branded part. Manufactured to the original dimensions and ratings for thread, dimensions, and filtration performance, it offers the same fit and function with significant cost savings.
Installation follows the same steps as the OEM filter. Remove the old element, clean the housing sealing face, lubricate the new seal with clean hydraulic oil, and spin the filter on until the seal contacts the base. Tighten according to your equipment manual.
