Electronic Timer Condensate Drain Valve for A...:
Nitrile (NBR) O-Ring Assortment Kit, Metric, ...: | Burst Pressure | 23 bar (334 PSI) |
| Element Collapse pressure | 5 bar (73 PSI) |
| Filtration Media | Borosilicate micro glass fibre 3 µm |
| Media type | Borosilicate micro glass fibre |
| Filtration Rating | 3 µm |
| Permissible Flow | 300 m3/h |
| Flow direction | Out-In |
| Body Height | 305 mm (12") |
| Height-1 | 1.5 mm (1/16") |
| Total Height | 306.5 mm (12 1/16") |
| Type | o-ring |
| Thread | UN 1.1/2 inch Female Bottom 16 |
| Type | UN |
| Thread Size | 1.1/2 inch |
| Orientation | Female |
| Position | Bottom |
| Product Net Weight | 2.78 kg (6.13 lbs) |
| Working Pressure | 20 bar (290 PSI) |
| Outer Diameter | 137 mm (5 13/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Atlas Copco | 1202539500 |
| Atlas Copco | 1202834300 |
| Atlas Copco | 1614567300 |
| Fai Filtri | DSP-400-6-HC |
| HiFi Filter | OV 6077 |
| Noitech | NS 000350 |
| Oxfil | SP.5003 |
| Sotras | DF 5003 |
| Spare Part Mart | SPM-SEP-1080 |
| T.G. Filter | 140305 A |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| Oxfil | USD 94.15 | 16 Oct 2026 |
| The Air Market | USD 116.84 | 15 Oct 2026 |
| Air Compressor Services | USD 189.50 | 15 Oct 2026 |
| FilterFinder Online | USD 320.00 | 15 Oct 2026 |
| Compressor Parts Express | USD 567.65 | 15 Oct 2026 |
| Spare Part Mart | USD 75.32 | Today |
Our price of USD 75.32 is 20% to 87% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
High-Flow Continuous Duty
In applications requiring constant compressed air flow up to 300 m³/h, such as large manufacturing plants, this separator maintains filtration efficiency without pressure drop, supporting uninterrupted production.
Dusty or Contaminated Environments
For compressors operating in dusty workshops or outdoor sites, the 3 µm borosilicate media captures fine particulates, protecting downstream equipment and reducing maintenance frequency.
Multi-Compressor Maintenance Consolidation
Facilities with mixed fleets from Atlas Copco, Almig, Alup, Gardner, and Ingersoll can standardise on this separator, simplifying inventory management and reducing stockholding costs.
High-Pressure Systems
With a working pressure of 20 bar and burst pressure of 23 bar, this separator is suitable for compressed air systems operating at elevated pressures, ensuring safety and reliability in heavy-duty industrial processes.
Check your compressor's model and serial number against our verified compatibility list. This separator fits specific Atlas Copco GA series, Almig VARIABLE/FLEX/BELT/DIRECT models, Alup SCK/SOLO/ALLEGRO series, Gardner VS/ESM models, and Ingersoll NIRVANA/SSR UP/SSR M/R series with the specified serial number ranges.
This separator uses borosilicate micro glass fibre media with a filtration rating of 3 µm, effectively removing solid particulates and oil aerosols from compressed air.
The separator has an outer diameter of 137 mm, a total height of 306.5 mm, and a body height of 305 mm. It features a UN 1.1/2 inch female thread at the bottom, with a thread orientation of female and position bottom.
This is an aftermarket replacement built to the original dimensions and ratings. It is not a genuine OEM part but offers equivalent performance and fitment for the listed brands, providing a cost-effective alternative.
Installation involves removing the old separator and replacing it with this separator, ensuring the O-ring is seated properly. The flow direction is out-in, so verify correct orientation. Tighten the thread to manufacturer specifications.
