Nitrile (NBR) O-Ring Assortment Kit, Metric, ...: | Part Type | Compressed air activated carbon filter element |
| Replaces | Pneumatech 2258290142 |
| Filtration Rating | Activated carbon (oil vapour removal) |
| Filter Media | Activated carbon in a perforated steel tube |
| Medium | Compressed air |
| Cross reference | HiFi Filter SI 54083 |
| Stat. HS-Code | 842199 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| HiFi Filter | SI 54083 |
| Pneumatech | 2258290142 |
| Spare Part Mart | SPM-INF-3779 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| Air Compressor Services | USD 218.00 | 21 Oct 2026 |
| FilterFinder Online | USD 235.00 | 21 Oct 2026 |
| Spare Part Mart | USD 174.40 | Today |
Our price of USD 174.40 is 20% to 26% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Oil vapour and odour removal
Activated carbon adsorbs the oil vapour and smell left after a 0.01 µm coalescing element.
Food, beverage and pharmaceutical air
Air in contact with product is usually passed through a carbon stage after the 0.01 µm stage.
Protecting the carbon
Liquid oil saturates carbon early, so change the 0.01 µm element ahead of it at the same service.
Change interval
Carbon does not show a pressure drop when spent. Change it at least every 1,000 operating hours or six months, and sooner if the air smells of oil.
No. It is an aftermarket element made to fit. It is not made by or affiliated with Pneumatech, Quincy or Chicago Pneumatic; the number 2258290142 is shown only so you can match the part you are replacing.
Check the number on the old element or in the filter's parts list. If it reads 2258290142, or the HiFi equivalent SI 54083, this is the replacement.
Yes. Activated carbon is meant for oil vapour, not liquid oil or particles, so it must sit after a 0.01 µm coalescing element. Without one the carbon saturates quickly.
Fit the new O ring, check the bowl seal and make sure the auto drain is clear before putting the line back under pressure.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
