Nitrile (NBR) O-Ring Assortment Kit, Metric, ...: | Part Type | Compressed Air Filter Element |
| Replaces | Kaeser 9.4580.1 |
| Outside Diameter | 86 mm (3.39 in) |
| Height | 254 mm (10.00 in) |
| Media | Coalescing filter media |
| Stat. HS-Code | 842139 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Almig | AK10/30 |
| Alup | AK10/30 |
| Atlas Copco | 2255291710 |
| Boge | 1/180AU |
| Donaldson | AK 10/3 |
| Donaldson | AK 10/30 |
| Gardner Denver | GDK10/30 |
| Grassair | GAE180 |
| HiFi Filter | SI 10103 |
| Kaeser | 10/30A |
| Kaeser | 9.2167.0 |
| Kaeser | 9.4580.1 |
| Mann-Filter / Mann & Hummell | LD 9010/3 |
| Noitech | NM 016990 |
| Omega Air | 1010100103866 |
| Omega Air | ODO 1030 AK/A |
| Sotras | SM 9169 |
| Spare Part Mart | SPM-INF-3562 |
| Ultrafilter | AK10/30 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| Oxfil | USD 71.73 | 19 Oct 2026 |
| The Air Market | USD 161.30 | 19 Oct 2026 |
| FilterFinder Online | USD 272.00 | 19 Oct 2026 |
| Spare Part Mart | USD 57.38 | Today |
Our price of USD 57.38 is 20% to 79% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Scheduled service
Change the element at least once a year, or sooner if the differential pressure gauge on the housing shows it is loaded.
Breakdown spares
Keep one on the shelf so a loaded compressed air filter element does not stop the machine while parts are ordered.
Workshop and fleet stock
Workshops looking after several machines can stock this one element under any of its 18 part numbers.
No. It is an aftermarket compressed air filter element made to replace the Kaeser 9.4580.1. It is not made by or affiliated with Kaeser, and the part number is used only to show what it replaces.
It replaces the element numbered Kaeser 9.4580.1 and the other numbers in the cross reference table. Check the number on the old element or in the machine's parts list, or measure it: this one is 86 mm (3.39 in) across and 254 mm (10.00 in) high.
Change the element at least once a year, or sooner if the differential pressure gauge on the housing shows it is loaded.
Isolate the filter housing and let the pressure out. Unscrew the bowl, pull the old element off its seat, fit the new element with its O rings lightly lubricated, refit the bowl and pressurise slowly. Check for leaks.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
