Nitrile (NBR) O-Ring Assortment Kit, Metric, ...:
Universal Filter Strap Wrench for Oil, Fuel a...: | Filtration Media | Inorganic Microfibers 25 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 25 µm |
| Flow direction | Out-In |
| Total Height | 483 mm (19") |
| Bypass Valve Opening Pressure | 3 bar (44 PSI) |
| Largest Inner Diameter | 96.5 mm (3 13/16") |
| Smallest Inner Diameter | 65.5 mm (2 19/32") |
| Outer Diameter | 143 mm (5 5/8") |
| Largest Outer Diameter | 143.5 mm (5 21/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Airfil | AFPOVL28020 |
| Behringer | BE1300R25A43 |
| Comex | H1300RN20 |
| Comex | H1300RN2020 |
| Donaldson | P170890 |
| Donaldson | P173184 |
| Epe | 101300H20SL0006P |
| Epe | 101300LAH20SL0006P |
| Epe | 101300LAH20SL0006PX |
| Epe | 101300LAH20SL006P |
| Epe | 101300LAH20XL006M |
| Epe | E30TR1300H20 |
| Epe | E30TR1300H20LLLA |
| Fai Filtri | R-1300-A25-NHA |
| Fleetguard | HF6855 |
| Fleetguard | ST1161 |
| Giporec | GP11950 |
| Hy-Pro | HP95RNL1825MB |
| Hy-Pro | HP95RNL1825MSB |
| Hydac | 1263054 |
| Hydac | 1263755 |
| Hydac | 1300R020BN |
| Hydac | 1300R020BN3HC |
| Hydac | 1300R020BN4HC |
| Hydac | 1300R020BNHC |
| Hydac | 2059112 |
| Internormen | 0201300R20VG30HCSP |
| Internormen | 0201300R20VG30SP |
| Internormen | 310560 |
| Mahle | 890018SMX16 |
| Mann-Filter / Mann & Hummel | HD101582 |
| Oxfil | HF.9291 |
| Pall | HC2295FKT18H |
| Pall | HC2296FKT18H50 |
| Parker Parfit | 934479 |
| Parker Parfit | 938304Q |
| Parker Parfit | GO3357 |
| Parker Parfit | GO3361 |
| Schroeder | SBF1300RZ25B |
| Spare Part Mart | SPM-HYD-1821 |
| ST Separat Tech | H130R20N |
| ST Separat Tech | H300R20N |
| ST Separat Tech | ST2119 |
| Stauff | RE300E20B |
| Stauff | RE300G20B |
| Woodgate | WGHH13020RB |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| SONA Filtration | USD 166.18 | 13 Oct 2026 |
| Filtration Point | USD 191.40 | 13 Oct 2026 |
| Cardinal Filters | USD 216.37 | 13 Oct 2026 |
| Oxfil | USD 339.60 | 16 Oct 2026 |
| Hydrafil | USD 357.95 | 13 Oct 2026 |
| FilterFinder Online | USD 372.00 | 13 Oct 2026 |
| Spare Part Mart | USD 132.94 | Today |
Our price of USD 132.94 is 20% to 64% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Continuous-Duty Manufacturing
In production lines running 24/7, this filter keeps hydraulic oil clean to reduce wear on pumps and valves. Its high dirt-holding capacity minimises unplanned downtime, helping to sustain throughput and lower per-part costs.
Harsh Environment Operations
Equipment exposed to dust, moisture, or heavy vibration demands reliable filtration. The inorganic microfiber media resists degradation and maintains a consistent 25-micron barrier, protecting sensitive hydraulics in construction, mining, or agricultural machinery.
Scheduled Fleet Maintenance
For workshops managing multiple Hydac-equipped machines, this filter enables predictable change intervals. The aftermarket pricing cuts life-cycle costs, and planning bulk replacements becomes straightforward with one compatible element across many legacy systems.
Multi-Brand Inventory Consolidation
Because this filter crosses dozens of brand part numbers, from Donaldson to Pall to Mann-Filter, service centres can stock a single aftermarket filter. This simplifies ordering, reduces shelf space, and still guarantees fit for Hydac housings.
Check your existing filter’s dimensions against this filter: total height 483 mm, outer diameter 143 mm, largest inner diameter 96.5 mm, and smallest inner diameter 65.5 mm. As long as these match your housing, the filter will fit. There are no special mounting requirements beyond correct sizing.
It delivers a 25-micron absolute rating using inorganic microfiber media. This material traps hard particles like silt and wear debris while allowing clean oil to flow. The out-to-in flow path maximises contaminant capture without excessive pressure drop, keeping hydraulic systems operating within clean tolerances.
This filter is engineered to match the critical internal diameters, largest ID 96.5 mm and smallest ID 65.5 mm, that locate on the filter head and seal. There are no threaded connections; the element drops into standard Hydac housings. Always compare your old element’s IDs to these specifications.
No, it is an aftermarket filter element built to mirror OEM dimensions and media performance. It provides equivalent contaminant control at a significantly lower cost. This makes it an attractive choice for cost reduction without sacrificing reliability.
Relieve system pressure, remove the housing cover, and take out the old filter. Clean the housing interior and verify the bypass valve moves freely. Insert the new this filter ensuring the flow direction (out-in) is correct, then reassemble. It is a simple drop-in replacement that requires no special tools.
We ship worldwide with tracking on every order. All purchases are covered by a 30-day money-back guarantee so you can return the filter if it does not meet your needs. We also offer a price-beat guarantee, if you find a qualifying lower price elsewhere, we will beat it.
