| Part Type | Pressure filter element |
| Replaces | Sofima CCH1512C1 / Sofima CH151FC21 |
| Filtration Media | Glass fibre |
| Filtration Rating | 5 µm, Beta 6(c) = 1,000 (ISO 16889) |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton) |
| Largest Outer Diameter | 45 mm (1 25/32") |
| Largest Inner Diameter | 25.4 mm (1") |
| Total Height | 86.1 mm (3 3/8") |
| End Configuration | Single open end |
| Collapse Rating | 210 bar (3,045 psid) |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Sofima | CCH1512C1 |
| Sofima | CH151FC21 |
| Spare Part Mart | SPM-HYD-2493 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-63% on Spare Part Mart SPM-HYD-2493 buying from SPM.
Pressure line protection
Sofima pressure filters sit after the pump to protect valves and actuators. A fresh element keeps the circuit at its target cleanliness code.
Industrial power units
Italian built presses, machine tools and plastics machines often carry Sofima filters on the power unit. Keeping a spare element means a change can happen at the next planned stop.
Mobile hydraulics
Sofima elements are fitted to agricultural and construction machines from Italian builders, on both pressure and return circuits.
Planned maintenance stock
Sites running several machines on the same filter can hold elements for scheduled changes at a lower price than buying OEM every time.
No. It is an aftermarket element made to the dimensions and filtration grade of the Sofima CCH1512C1. It is not made by or affiliated with Sofima or UFI, and the Sofima part number is used only to show what it replaces.
Yes if your filter takes the Sofima CCH1512C1. Check the old element: 45 mm outside diameter, 25.4 mm bore and 86.1 mm overall length.
Sofima's last letters give the media and grade. FC is the 5 µm glass fibre grade, FD the 10 µm and FV the 25 µm, so the same body is sold in several grades. Fit the grade your filter was designed for.
Fluorocarbon (FKM / Viton) O-rings, which suit mineral oil, synthetic and most fire resistant fluids and higher oil temperatures.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
