| Part Type | Filter element |
| Replaces | Kaydon KMP9600A03V08 |
| Filtration Media | Pleated glass fibre (microglass) |
| Filtration Rating | 3 µm, beta 1000 (ISO 16889) |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton) O-ring |
| Largest Outer Diameter | 78.5 mm (3 3/32") |
| Largest Inner Diameter | 43.7 mm (1 23/32") |
| Total Height | 208.8 mm (8 7/32") |
| Construction | Single open end |
| Element Size | Kaydon KMP9600, 8 in |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Kaydon | KMP9600A03V08 |
| Spare Part Mart | SPM-HYD-2687 |
We check what other aftermarket sellers charge for this same part. Their prices on the date we checked:
| Seller | Price | Checked |
|---|---|---|
| SONA Filtration | USD 38.81 | 5 Oct 2026 |
| Filtration Point | USD 45.37 | 5 Oct 2026 |
| MicroFit | USD 61.00 | 5 Oct 2026 |
| Spare Part Mart | USD 31.05 | Today |
Our price of USD 31.05 is 20% to 49% less than these sellers.
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
Hydraulic pressure and return lines
Kaydon KMP filters protect pumps, valves and actuators on industrial power units. The 3 µm grade suits servo and proportional valve circuits.
Lube oil systems
The same element cleans gearbox and bearing lube circuits where fine filtration extends component life.
Fire resistant and synthetic fluids
Fluorocarbon seals suit synthetic and most fire resistant fluids as well as mineral oil.
Planned maintenance stock
Sites with several filters on the same element can hold stock for scheduled changes at a lower price than buying OEM every time.
No. It is an aftermarket element made to the dimensions and filtration grade of the Kaydon KMP9600A03V08. It is not made by or affiliated with Kaydon, and the part number is used only to show what it replaces.
Yes if your filter takes the Kaydon KMP9600A03V08. Check the old element: 78.5 mm outside diameter, 43.7 mm bore and 208.8 mm overall length.
KMP9600 is the filter series, A03 the 3 µm glass fibre grade, V the fluorocarbon seal and 08 the nominal 8 in length.
A fluorocarbon (FKM / Viton) O-ring on the open end. It suits mineral oil, synthetic and most fire resistant fluids and higher oil temperatures.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
