| Part Type | Filter element |
| Replaces | Sofima CLE070MN1 |
| Filtration Media | Pleated stainless steel wire mesh |
| Filtration Rating | 125 µm, stainless steel mesh |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR) |
| Largest Outer Diameter | 99 mm (3 29/32") |
| Largest Inner Diameter | 41 mm (1 5/8") |
| Total Height | 173 mm (6 13/16") |
| Collapse Rating | 4 bar (58 psid) |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Sofima | CLE070MN1 |
| Spare Part Mart | SPM-HYD-2490 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-48% on Sofima CLE070MN1 buying from SPM.
Suction and return lines
The 125 µm stainless mesh grade gives coarse protection to pumps and return lines without the pressure drop of a fine element.
Lube oil and gearbox circuits
Mesh elements suit lubrication circuits on gearboxes and pumps, where coarse protection is all the circuit needs.
Industrial power units
Sofima filters are fitted to power units on Italian built machines. The mesh element is the one used where the fine filtration happens elsewhere.
Cleanable elements
Stainless mesh elements can be washed and refitted, so a site can keep one spare in rotation while the other is cleaned.
No. It is an aftermarket element made to the dimensions and filtration grade of the Sofima CLE070MN1. It is not made by or affiliated with Sofima or UFI, and the Sofima part number is used only to show what it replaces.
Yes if your filter takes the Sofima CLE070MN1. Check the old element: 99 mm outside diameter, 41 mm bore and 173 mm overall length.
Yes. Stainless mesh elements can be washed in clean solvent and blown out from the inside, then refitted if the mesh is undamaged. Replace it once it no longer cleans up or the pleats are damaged.
Nitrile (NBR) seals, which suit mineral oil based hydraulic fluids. Ask us before ordering if your system runs a fire resistant or synthetic ester fluid.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
