| Part Type | Hydraulic and lube oil filter element |
| Replaces | Pall HC9100FKN13H |
| Interchange | Hydac 1269117 (1.12.13 D 06 BN4) |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 7 µm(c), Pall N grade |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR) |
| Largest Outer Diameter | 70 mm (2 3/4") |
| Largest Inner Diameter | 34 mm (1 11/32") |
| Total Height | 330 mm (13") |
| Nominal Length | 13 in |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Hydac | 1.12.13 D 06 BN4 |
| Hydac | 1269117 |
| Pall | HC9100FKN13H |
| Spare Part Mart | SPM-HYD-2201 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-36% on Hydac 1.12.13 D 06 BN4 buying from SPM.
Hydraulic power units
Pressure and return line housings on industrial power units that take the HC9100 13 inch element. The 7 µm(c) grade holds the fluid cleanliness the pumps and valves were specified for.
Gearbox and turbine lube oil
Lube oil skids on gearboxes, compressors and turbines use the HC9100 element in duplex housings. Keeping spare elements on the shelf lets you change over the moment the differential pressure indicator trips.
Test stands and flushing rigs
Flushing a new or repaired system to its target ISO cleanliness code takes several element changes. An aftermarket element at a lower price makes repeated flushing cycles cheaper.
Planned maintenance stock
Sites that run several housings on the Pall HC9100FKN13H can hold a stock of elements for scheduled changes without paying OEM prices for every one.
No. It is an aftermarket element made to the dimensions and filtration grade of the Pall HC9100FKN13H. It is not made by or affiliated with Pall, and Pall part numbers are used only to show what it replaces.
Yes if your housing takes the Pall HC9100FKN13H or the Hydac 1.12.13 D 06 BN4. Check the old element: 70 mm outside diameter, 34 mm bore and 330 mm overall length, with an O-ring seal at the open end.
It is the particle size the media captures at a beta ratio of 1000 or more under the ISO 16889 multipass test, so it removes at least 99.9% of particles of 7 µm and larger on each pass.
H means nitrile (NBR) seals, which suit mineral hydraulic and lube oils. The Z version (HC9100FKN13Z) has fluorocarbon seals for phosphate ester fluids and higher temperatures; this listing is the nitrile H version.
Change it when the housing's differential pressure indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first. A loaded element that goes into bypass lets dirty oil through.
