| Part Type | Coreless filter element |
| Replaces | Hy-Pro HP8314L1325MV / Pall HC8314FKT13Z |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 20 to 25 µm, beta 1000 (ISO 16889) |
| Flow Direction | Out-In |
| Seal Material | Fluorocarbon (FKM / Viton) |
| Largest Outer Diameter | 152 mm (5 31/32") |
| Largest Inner Diameter | 96 mm (3 25/32") |
| Total Height | 273 mm (10 3/4") |
| Construction | Coreless (the core stays in the filter housing), plastic end caps with lifting handle |
| Collapse Rating | 10 bar (150 psid) |
| Nominal Length | 13 in |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Hy-Pro | HP8314L1325MV |
| Pall | HC8314FKT13Z |
| Spare Part Mart | SPM-HYD-2638 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-85% on Pall HC8314FKT13Z buying from SPM.
Industrial power units
Hy-Pro and Pall elements sit on the power units of presses, machine tools, plastics machines and test rigs. A fresh element keeps valves and pumps at the cleanliness they were designed for.
Turbine and lube oil systems
The same element sizes run on turbine lube and control oil skids, gearbox lubrication and compressor lube systems, where clean oil decides bearing life.
Steel, paper and energy plants
Mill and power plant hydraulic systems use these elements in duplex filters, so the change can happen on line as soon as the indicator trips.
Planned maintenance stock
Sites with several filters on the same element can hold stock for scheduled changes at a lower price than buying OEM every time.
No. It is an aftermarket element made to the dimensions and filtration grade of the Hy-Pro HP8314L1325MV / Pall HC8314FKT13Z. It is not made by or affiliated with Hy-Pro or Pall, and their part numbers are used only to show what it replaces.
Yes if your filter takes the Hy-Pro HP8314L1325MV or Pall HC8314FKT13Z. Check the old element: 152 mm outside diameter, 96 mm bore and 273 mm overall length.
The element has no inner support tube. The perforated core is part of the filter housing and stays in place, and the new element slides over it. Do not fit a coreless element in a housing that has no core.
Fluorocarbon (FKM / Viton) seals, shown by the V at the end of the Hy-Pro number and the Z at the end of the Pall number. They suit mineral oil, synthetic and most fire resistant fluids and higher oil temperatures.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
