| Element Collapse pressure | 210 bar (3046 PSI) |
| Filtration Media | Inorganic Microfibers 5 µm |
| Media type | Inorganic Microfibers |
| Filtration Rating | 5 µm |
| Flow direction | Out-In |
| Total Height | 170.5 mm (6 23/32") |
| Largest Inner Diameter | 25.5 mm (1") |
| Largest Outer Diameter | 47 mm (1 27/32") |
| Stat. HS-Code | 84149000 |
| Country of Manufacture | China |
| Brand | Code |
|---|---|
| Behringer | BE251703A |
| Comex | M0008DH2003 |
| Comex | M0008DH3 |
| Fai Filtri | CF-108-A03-HA |
| Fleetguard | ST1519 |
| Hy-Pro | HP251L73M |
| Hydac | 1268890 |
| Hydac | 2080D03BH |
| Internormen | 04PI22083VGHREO |
| Internormen | 301035 |
| Mahle | 7680200 |
| Mahle | 9650510153 |
| Mahle | PI2208SMXVST3 |
| Mann-Filter / Mann & Hummel | HD5133 |
| Oxfil | HF.7422 |
| Parker Parfit | 935226 |
| Parker Parfit | GO2841 |
| Parker Parfit | PR2841 |
| PTI | PG025GU |
| Sofima (UFI) | SPI2208FT21 |
| Spare Part Mart | SPM-HYD-1154 |
| Stauff | SL020F03B |
Found this part cheaper somewhere else? Send us the listing and we will beat it by 5% under our Price Beat Guarantee. Every order is also covered by our 30 day money back guarantee.
High-Pressure Hydraulic Systems
In applications where hydraulic pressures reach up to 210 bar, this filter element maintains structural integrity and prevents collapse, ensuring continuous protection of sensitive components.
Fine Filtration for Sensitive Equipment
The 5 µm inorganic microfibers capture fine particles that can cause wear in servo valves and precision actuators, reducing downtime and extending equipment life.
Out-In Flow Configurations
Designed for systems with out-in flow direction, this element is ideal for return-line or off-line filtration where fluid flows from the outside to the inside of the element.
Inventory Consolidation
Cross-referencing multiple OEM brands (Hydac, Mahle, Parker Parfit, etc.), this single element simplifies stock management for facilities using diverse equipment.
Check your current filter's dimensions: height 170.5 mm, outer diameter 47 mm, inner diameter 25.5 mm. Also ensure your housing accepts an out-in flow direction and a 210 bar collapse pressure rating.
This filter uses inorganic microfibers with a 5 µm filtration rating, providing fine particle removal for hydraulic systems.
Yes, it is a direct replacement for Hydac filters of equivalent dimensions and specifications. Verify your housing model matches the size and flow direction.
This is an aftermarket replacement built to match OEM specifications. It is not branded as genuine but offers equivalent performance.
Installation is similar to OEM elements: ensure the housing is clean, insert the element with the correct orientation (out-in flow), and tighten the cover to the recommended torque.
