| Part Type | Return filter element |
| Replaces | Sofima RC110FC1 |
| Filtration Media | Glass fibre |
| Filtration Rating | 5 µm, glass fibre |
| Flow Direction | In-Out |
| Seal Material | Nitrile (NBR) |
| Largest Outer Diameter | 71.9 mm (2 27/32") |
| Largest Inner Diameter | 44.7 mm (1 3/4") |
| Total Height | 106.2 mm (4 3/16") |
| Collapse Rating | 10 bar (150 psid) |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Sofima | RC110FC1 |
| Spare Part Mart | SPM-HYD-2488 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving 20-66% on Sofima RC110FC1 buying from SPM.
Return line filtration
Return filters clean all the oil coming back to the tank, which is where most wear debris is caught. A clean element keeps the whole circuit healthy.
Industrial power units
Sofima return and tank top filters are fitted to power units on Italian presses, machine tools and plastics machines.
Mobile hydraulics
Agricultural and construction machines from Italian builders use Sofima tank top filters on the main return line.
Planned maintenance stock
Holding a spare element means the change can happen as soon as the clogging indicator trips, not after a parts order.
No. It is an aftermarket element made to the dimensions and filtration grade of the Sofima RC110FC1. It is not made by or affiliated with Sofima or UFI, and the Sofima part number is used only to show what it replaces.
Yes if your filter takes the Sofima RC110FC1. Check the old element: 71.9 mm outside diameter, 44.7 mm bore and 106.2 mm overall length.
Sofima's last letters give the media and grade. FC is the 5 µm glass fibre grade, FD the 10 µm and FV the 25 µm, so the same body is sold in several grades. Fit the grade your filter was designed for.
Nitrile (NBR) seals, which suit mineral oil based hydraulic fluids. Ask us before ordering if your system runs a fire resistant or synthetic ester fluid.
Change it when the filter's clogging indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first.
Yes, we ship worldwide. Shipping is calculated at checkout, and every order is covered by our 30 day money back guarantee and price beat guarantee.
