| Part Type | Pressure filter element |
| Replaces | Internormen 01.E 60.3VG.HR.E.P (article 300072) |
| Filtration Media | Pleated glass fibre |
| Filtration Rating | 5 µm, Internormen 3VG glass fibre grade |
| Flow Direction | Out-In |
| Seal Material | Nitrile (NBR) |
| Largest Outer Diameter | 45 mm (1 25/32") |
| Largest Inner Diameter | 22 mm (7/8") |
| Total Height | 110 mm (4 11/32") |
| Nominal Size | 60 |
| End Configuration | Single open end |
| Collapse Rating | 160 bar (2,320 psid), HR high collapse |
| Stat. HS-Code | 842129 |
| Brand | Code |
|---|---|
| Internormen | 01.E60.3VG.HR.E.P |
| Internormen | 300072 |
| Spare Part Mart | SPM-HYD-2228 |
Price Beat Guarantee: We've crawled the internet to guarantee you're getting the best price. Here's what competitors are selling this exact filter for:
You're saving approximately 20% on Spare Part Mart SPM-HYD-2228 buying from SPM.
This element replaces Internormen 01.E 60.3VG.HR.E.P (article 300072). It fits any filter housing built to take that element: 45 mm outside diameter, 22 mm bore, 110 mm long, single open end, with nitrile (NBR) seals.
To check, read the element number on the old element or on the housing data plate. Internormen element numbers read type, nominal size, grade, collapse rating and seal in that order, so 01.E 60 means the size 60 pressure element and 01.E 1201 the size 1201 element. Order the same size and grade as the one you are replacing.
Servo and proportional valve protection
A last chance pressure filter ahead of a servo or proportional valve stops particles reaching the spool. The 3VG grade is the usual choice here.
Machine tools and presses
Clamping, spindle and press circuits use small inline pressure filters. Clean oil keeps cycle times and positioning repeatable.
Test rigs and hydraulic power packs
Compact power units and test benches fit size 60 pressure filters on the pump outlet. A spare element keeps the rig running when the indicator trips.
Filters without bypass
The HR high collapse element is made for housings with no bypass valve, where the element has to withstand full system differential pressure.
No. It is an aftermarket element made to the dimensions and filtration grade of the Internormen 01.E60.3VG.HR.E.P (article number 300072). It is not made by or affiliated with Internormen or Eaton, and their part numbers are used only to show what it replaces.
Yes if your housing takes the Internormen 01.E60.3VG.HR.E.P (article 300072). Check the old element: 45 mm outside diameter, 22 mm bore and 110 mm overall length.
3VG is Internormen's code for its finest glass fibre (VG) media grade, rated at 5 µm retention. It is the grade used ahead of servo and proportional valves and on lube systems where fine particles cause wear.
In 01.E60.3VG.HR.E.P, E is the element design and the final P means nitrile (NBR) seals; the same element with V at the end has fluorocarbon (Viton) seals. HR means the high collapse design rated at 160 bar differential pressure.
Change it when the housing's differential pressure indicator shows the element is loaded, or at the interval in your maintenance plan, whichever comes first. A loaded element that goes into bypass lets dirty oil through.
